Adjusting headstock angle (fig. 33.1)

Loosen the two screws (1) on the frame r.h. side to

adjust the headstock angle.

Fully unscrew the screw (2) and turn the headstock end

(3) by 180° with a pin wrench.

Fully screw the screw (2). Grease the screw threadings

(1) with SHELL Retinax HDX2 and tighten to 22

Nm/16.22 ft.lbs.

Note

While performing the above, the handlebars should

not be fully turned.

When finished, the steering damper must be

repositioned. Undo the screw (4, fig. 33.2). Move the

damper rod joint to the frame hole (5). Tighten the screw

(4) previously removed.

Important

The steering lock can be used only if the headstock

tube is positioned at 24°30’. This adjustment is possible

for 748S, 996 and 996S models only.

fig. 33.1

fig. 33.2
