64
E
Electric system
Basic electric items are:
front headlamp consisting of the following:
12V-55W low beam unit, poly-ellipsoidal with capacitor;
12V-55W high beam unit;
parking light with no. 2 12V-5W bulbs.
When turning on the high beam unit, the low beam unit
does not turn off. Therefore, total lighting power is given
by the sum of both bulbs.
Instrument panel, 12V-1.2W warning lights; 12V-2W
instrument lights.
Electrical controls on handlebars.
Turn indicators, 12V-10W bulbs.
Horn.
Stop light switches.
Battery 12V-16 A.
Generator 12V-520W.
Electronic voltage regulator (rectifier), protected by a
40 A fuse near the battery.
Starter motor, 12V-0.7 kW.
Tail light, 12V-5/21W double-filament bulb for stop light
and parking light; 12V-5W bulb for number plate light.
Note
See “Replacing bulbs” on pages 48, 49 and 50 for
relevant instructions.
Fuses
The main fuse box (fig. 45.1) is located on the frame right
side.
To expose the fuses, take off the box protective cover.
Mounting position and ampere capacity are marked on it.
Two fuses on the right side of the rear sub-frame protect
the relays of the injection system (1, fig. 45.2).
The fuse located on a side of the battery (fig. 45.3)
protects the electronic regulator. Remove the fuse cap (2)
to expose it.
A blown fuse is identified by the interrupted inner
filament (3, fig. 45.4).
Important
Switch the ignition key to OFF before replacing the
fuse to avoid possible short circuits.
Warning
Never use a fuse with a rating other than specified.
Failure to observe this rule may damage the electric
system or even lead to fire.
