12 Engine electrical system
Connection Nm Nm
Starter motor to engine 20 20
Starter cover to gearbox housing 7 –
Positive lead to starter motor 10 10
Alternator to alternator support cover 20 20
Tensioning and retaining strap at alternator 20 20
Spacer at alternator 20 20
Positive lead to alternator 15 15
Belt pulley at alternator 50 50
Belt pulley to crankshaft 50 50
Poly-V belt preload 8 8
Spark plug 20 20
13 Fuel preparation and control
Temperature sensor on engine block 25 25
16 Fuel tank and lines
Fuel tank to rear frame 22 22
Fuel pump assembly to tank 6 6
18 Exhaust system
Muffler to footrest 35 35
Manifold to cylinder head (with strap) 22 22
(with jacket pipe) 18 18
Muffler to support plate for center stand 20 20
Clip on muffler 50 50
Grease clamping face with Never Seez
Oxygen sensor (lambda probe) to muffler 55 55
Grease with Never Seez
Model R 1100 RS R 1100 RT
