31.5
Technical Data R 850 GS R 1100 GS
Front suspension
Type BMW Telelever with external suspension strut
Telescopic fork
Front wheel caster in normal-load position
(with rider weighing 85 kg (187.425 lb)) mm (in) 115 (4.5275) 115 (4.5275)
Steering lock angle ° 42 42
Total suspension travel mm (in) 190 190
Fixed tube surface Hard chrome plated Hard chrome plated
Extl. dia. of fixed fork tubes mm (in) 35,0 (1.3779) 35,0 (1.3779)
Maximum permissible runout
of fixed fork tube mm (in) 0,4 (0.01574) 0,4 (0.01574)
Telescopic fork oil – approved grades BMW telescopic fork oil BMW telescopic fork oil
Fill quantity in each fork leg l (Imp. pints) 0.470 (0.827) 0.470 (0.827)
Suspension strut
Type Suspension strut with 5 spring preload settings,
twin-tube, gas-filled shock absorber
