34.4
Technical Data R 1100 RT
Brake fluid DOT 4
Minimum lining thickness mm (in) Wear indicator
Front wheel
Brake disc dia. mm (in) 305 (12.0079)
Brake disc thickness mm (in) 5
± 0.1
(0.1969
± 0.003937
)
Minimum thickness mm (in) 4.5 (0.1772)
Brake pad surface area cm
2
(sq.in)
100 (15,5)
Piston dia. in brake caliper mm (in) 32/34 (1.2598/1.3386)
Piston diameter in handlebar lever cylinder mm (in) 20 (0.787)
Sensor gap, front mm (in) 0.45...0.55
(0.0177...0.02165)
Brake pad Semi-metallic
Rear wheel
Brake disc dia. mm (in) 276 (10.866)
Brake disc thickness mm (in) 5.0 (0.1969)
Minimum thickness mm (in) 4.5 (0.177)
Permissible lateral runout mm (in) 0.15 (0.0059)
Brake pad surface area cm
2
(sq.in)
34 (5.27)
Piston dia. in brake caliper mm (in) 26 (1.0236)
with insulating piston
Piston dia. in foot brake cylinder mm (in) 12 (0.4724)
Sensor gap, rear mm (in) 0.45...0.55
(0.0177...0.02165)
Brake pad Semi-metallic
