11.35
Connecting rod
Big end bore dia. mm (in) 51.000...51.013
(2.00787...2.008386)
51.000...51.013
(2.00787...2.008386)
Big end bearing dia. mm (in) 48.016...48.050
(1.89039...1.89173)
48.016...48.050
(1.89039...1.89173)
Radial clearance mm (in) 0.025...0.075
(0.000984...0.0029527)
0.025...0.075
(0.000984...0.0029527)
Wear limit mm (in) 0.13 (0.001118) 0.13 (0.001118)
Width of big end bearing eye mm (in) 21.883...21.935
(0.86154...0.86358)
21.883...21.935
(0.86154...0.86358)
Conrod end float mm (in) 0.130...0.312
(0.005118...0.0122834)
0.130...0.312
(0.005118...0.0122834)
Wear limit mm (in) 0.5 (0.019685) 0.5 (0.019685)
Small end bearing bore dia. mm (in) 22.015...22.025
(0.86673...0.867126)
22.015...22.025
(0.86673...0.867126)
Radial clearance mm (in) 0.015...0.030
(0.0005905...0.0018)
0.015...0.030
(0.0005905...0.0018)
Wear limit mm (in) 0.06 (0.0023622) 0.06 (0.0023622)
Distance between centers mm (in) 125 (4.92126) 125 (4.92126)
Max. deviation from parallel of conrod bores
at 150 mm spacing mm (in) 0.07 (0.0027559) 0.07 (0.0027559)
Cylinders
Bore 20 mm (0.7874 in)
from top edge
20 mm (0.7874 in)
from top edge
A mm (in) 87.492...87.500
(3.444567...3.44489)
98.992...99.000
(3.89732...3.897638)
Wear limit mm (in) 87.550 (3.44685) 99.050 (3.899606)
B mm (in) 87.500...87.508
(3.44489...3.4452)
99.000...99.008
(3.897638...3.897953)
Wear limit mm (in) 87.558 (3.447165) 99.058 (3.899921)
Total wear clearance of piston and cylinder mm (in) 0.12 (0.0047244) 0.12 (0.0047244)
Permitted out-of-roundness of cylinder bore
20 mm from the top edge mm (in) 0.03 (0.0011811) 0.03 (0.0011811)
100 mm from the lower edge mm (in) 0.04 (0.0015748) 0.04 (0.0015748)
Pistons
Piston dia. (Measuring plane A —
a see Checking pistons
and cylinders)
A mm (in) 87.465...87.477
(3.4435...3.443977)
98.965...98.977
(3.89626...3.896732)
Wear limit mm (in) 87.390 (3.44055) 98.890 (3.8933)
B mm (in) 87.477...87.485
(3.443976...3.44429)
98.977...98.989
(3.896732...3.897204)
Wear limit mm (in) 87.400 (3.4409448) 98.900 (3.8937)
AB mm (in) 87.473...87.481
(3.44382...3.444134)
98.973...98.981
(3.89657...3.8968897)
Wear limit mm (in) 87.395 (3.44075) 98.895 (3.8935039)
Installed clearance mm (in) 0.011...0.035
(0.000433...0.0013779)
0.011...0.035
(0.000433...0.0013779)
Total wear clearance of piston and cylinder mm (in) 0.12 (0.0047244) 0.12 (0.0047244)
Technical Data R 850 R R 1100 R
