–2–
ENGINE SPECIFICATIONS
SPEC
Temp.
ENGINE SPECIFICATIONS
Item Standard Limit
Engine
Engine type
Displacement
Cylinder arrangement
Bore stroke
Compression ratio
Engine idling speed
Vacuum pressure at engine idling
speed
Standard compression pressure
(at sea level)
Liquid-cooled, 4-stroke, DOHC
998 cm
3
Forward-inclined parallel 4-cylinder
74 58 mm
11.8 : 1
1,000 1,100 r/min
29.3 kPa (220 mm Hg)
1,450 kPa (14.5 kgf/cm
2
) at 400 r/min
Fuel
Recommended fuel
Fuel tank capacity
Total (including reserve)
Reserve only
Regular unleaded gasoline
Unleaded fuel (for AUS)
18 L
3.8 L
Engine oil
Lubrication system
Recommended oil
Quantity
Total amount
Without oil filter cartridge
replacement
With oil filter cartridge replacement
Oil pressure (hot)
Relief valve opening pressure
Wet sump
SAE20W40SE or SAE10W30SE
3.6 L
2.7 L
2.9 L
45 kPa at 1,100 r/min
(0.45 kgf/cm
2
at 1,100 r/min)
490 570 kPa (4.9 5.7 kgf/cm
2
)
