bizhub 423/363/283/223 4-3

4.1 Windows Vista/Server 2008/7

4 Manual Installation Using the Add Printer Wizard

This chapter describes the procedure for installing the Windows printer driver using the standard Windows

Add Printer function.

4.1 Windows Vista/Server 2008/7

4.1.1 For network connection (LPR/Port 9100/SMB)

In Windows Vista/Server 2008/7, you can install the printer driver either by searching for the printer on the

network, or by creating a new printer port.

Settings for the machine

Before using Port9100, LPR, or SMB printing, you must configure the network settings for the machine.

d Reference

For details on the network settings for the machine, refer to the [User's Guide Network Administrator].

To use SMB printing in the IPv6 environment, [Direct Hosting Setting] for the machine must be enabled. For

details, refer to [User's Guide Network Administrator].

Installing the printer driver by searching for the printer using the Add Printer

Wizard

0 Installing the driver to Windows Vista/Server 2008/7-based computers requires the administrator au-

thority.

0 Since the printer is searched for during the installation, be sure to connect this machine to the network

before turning it on.

1 Insert the printer driver DVD-ROM for Windows into the DVD-ROM drive of the computer.

2 Click [Start], and then select [Control Panel].

3 Select the printer functions from [Hardware and Sound].

% In Windows Vista/Server 2008, click [Printers] under [Hardware and Sound]. When [Control Panel]

is displayed in Classic View, double-click [Printers].

% In Windows 7/Server 2008 R2, click [View devices and printers] under [Hardware and Sound]. When

[Control Panel] is displayed in an icon view, double-click [Devices and Printers].

4 On the toolbar, click the additional functions of the printer.

% In Windows Vista/Server 2008, click [Add a printer] on the toolbar.

% In Windows 7/Server 2008 R2, click [Add a printer] on the toolbar.

The [Add Printer] Wizard appears.

Items to be configured Description

IP address In [TCP/IP Settings] of the machine, specify the IP address.

RAW port number To use Port9100 printing:

In [TCP/IP Settings] for the machine, enable the RAW port number

(initial setting: [9100]).

LPD Setting To use LPR printing:

In [LPD Setting] for the machine, enable LPD printing.

SMB Setting To use SMB printing:

At [Print Settings] in [SMB Settings] for the machine, specify NetBI-

OS Name, Print Service Name, and Workgroup.
