Benq FP71G+S [5/35] Front view
![Benq FP71G+S [5/35] Front view](/views2/1122331/page5/bg5.png)
5 Getting to know your monitor
Getting to know your monitor
Front View
Back View
1. Power AC input jack
2. DVI-D Connector
3. D-Sub Connector
1
1
1
2
1 2 3
