Hyundai H-CMD7078 [41/83] Specification
![Hyundai H-CMD7078 [41/83] Specification](/views2/1123940/page41/bg29.png)
41
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General.
Power supply:
12 V DC (11 V 16 V)
Current consumption: 15 A
Maximum power output: 50 W x 4 channels
Dimensions (W x H x D) 178 x 50 x 165 mm
Working temperature range: -10º - +60º
FM Stereo Radio. Frequency range: 65.0 74.0/87.5 - 108.0 MHz
Usable sensitivity: 8 dB
MW Section. Frequency range: 522 kHz-1620 kHz
DVD Deck Specification Format DVD/SVCD/VCD/CD/MP3/CD-R/CD-RW/DVD±R
Video System/ Audio System Standard NTSC/PAL/AUTO / 24 bit/96 KHz
Loading System Auto Loading
Mounting Angle 0 to +/-30
Video Specification
Video System 16:9 and 4:3
Video Output level 1.0 Vp-p 75 ohms
Audio Specification
Maximum Output 2 Vrms (+/- 3 dB)
Frequency Response 20 to 20 KHz
S/N Ratio(A-vtd)/ Separation 80 dB/ 60 dB
Line out. Output: CD max 2000 mV
