CHAPTER 2 PCL - 17
3170CDW, L8250CDN, L8350CDW, L9200CDW,
L9300CDW,L2360DN,L2360DW,L2365DW,2560DN,2569DW and S7000DN.)
Select the height of free size paper: Esc&f#F (1/720 inch unit; for HL-3260N, 2460, 7050, 1850, 1870N,
5040, 5050, 5070N, 5140, 5150D, 5170DN, 2600CN, 3450CN, 2700CN, 2070N, 5240, 5250DN, 5270DN,
5280DW, 4040CN, 4050CDN,4070CDW, 2150N, 2170W, 5340D, 5350DN, 5370DW , 5380DN, 3070CW,
3075CW, 2250DN, 2270DW, 4140CN, 4150CDN, 4570CDW, 5440D, 5450DN, 5470DW, 6180DW,
3170CDW, L8250CDN, L8350CDW, L9200CDW,
L9300CDW,L2360DN,L2360DW,L2365DW,2560DN,2569DW and S7000DN.)
4.1.2. Media type selection
Esc&n# (27)(38)(110)# <1Bh><26h><6Eh>#
# stands for the media type of paper to be used.
Values for # correspond to the media type shown in the table.
Model
HL-
2070N/5240/5250D
N/5270DN/5280DW
/
2150N/2170W/
5340D/5350DN/537
0DW/5380DN
HL-
4040CN/4050C
DN/4070CDW/
3040CW/3045C
N/2250DN/227
0DW/5440D/54
50DN/5470DW
/6180DW
HL-
4140CN/415
0CDN/4570
CDW/3170C
DW/L8250C
DN/L8350C
DW/L9200C
DW/L9300C
DW/L2360D
N/L2360DW
/L2365DW/2
560DN/2569
DW
HL-
S7000DN
6WdPlain Set as Plain Paper.
8WdRegular
5WdThin Set as Thin Paper.
6WdThick Set as Thick Paper.
7WdThick2 Set as Thicker Paper.
5WdBond Set as Bond Paper.
13WdTransparency Set as Transparent Paper.
10WdEnvelopes Set as Envelope.
9WdEnvthick Set as Thick Envelope.
8WdEnvthin Set as Thin Envelope.
9WdRecycled Set as Recycled Paper.
9WdPostcard Set as Post Card.
6WdLabel Set as Label.
7WdGlossy Set as Glossy
4.1.3. Output tray
Esc&l#G (27)(38)(108)#(71) <1Bh><26h><6Ch>#<47h>
# denotes the output tray.
1:
Select the printer output tray.
3:
Select #1 bin. (CT:HL-8050N)
4:
Select #2 bin.
5:
Select #3 bin.
6:
Select #4 bin.
7:
Select #5 bin.
8:
Select #6 bin.
9:
Select #7 bin.
10:
Select #8 bin.
11:
Select #9 bin.
12:
Select #10 bin.
100:
Select the finisher tray (HL-3260N)
This command selects the specified output tray.
