Philips 42PFL7603/60 [3/3] Specifications
![Philips 42PFL7603/60 [3/3] Specifications](/views2/1124439/page3/bg3.png)
Issue date 2014-02-10
Version: 1.0.4
12 NC: 8670 000 51745
EAN: 87 12581 47792 9
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
AUDIO OUT
SERV. U
SPDIF
OUT
L
R
AUDIO IN
HDMI 1
AUDIO IN:
LEFT / RIGHT
HDMI 1 / DVI
HDMI 2 / DVI
HDMI 3 / DVI
EXT 2
(RGB/CVBS)
EXT 3
EXT 1
(RGB/CVBS)
HDMI 2HDMI 3
L
Pr
Pb
Y
R
TV ANTENNA
75X
42PFL7603/60
Specifications
LCD TV with Ambilight and Pixel Plus 3 HD
107cm (42") integrated digital
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 500 cd/m²
• Dynamic screen contrast: 30000:1
• Response time (typical): 5 ms
• Viewing angle: 176º (H) / 176º (V)
• Diagonal screen size: 42 inch / 107 cm
• Display screen type: LCD Full HD W-UXGA Act.
mat
r
ix
• Panel resolution: 1920x1080p
• Picture enhancement: Pixel Plus 3 HD, 3/2 - 2/2
mo
tio
n pull down, 3D Combfilter, Active Control
+ Light sensor, Color Enhancement, Color
Transient Improvement, Digital Noise Reduction,
Dynamic contrast enhancement, Luminance
Transient Improver, 1080p 24/25/30Hz processing,
1080p 50/60Hz processing, HD Natural Motion
• Screen enhancement: Anti-Reflection coated
sc
re
en
• Color cabinet: Black colour deco front & white
co
lour back cover
Ambilight
• Ambilight Features: Ambilight 2 Channel
• Preset modes: 4 Active Adaptive modes
Supported Display Resolution
• Computer formats
Res
olution Refresh rate
640 x 480 60, 72, 75, 85Hz
800 x 600 60, 72, 75, 85Hz
1024 x 768 60, 70, 75, 85Hz
Via HDMI/DVI
inpu
t
• Video formats
Res
olution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 24, 50, 60Hz
1080p 24, 25, 30Hz
Sound
• Equalizer: 5-bands
• Output power (RMS): 2 x 15W
• Sound Enhancement: Auto Volume Leveller,
Graphic
Equaliser
• Sound System: Nicam Stereo, Virtual Dolby Digital,
BBE
Loudspeakers
• Built-in speakers: 2
• Loudspeaker types: wOOx loudspeakers
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer, Wake up Clock
• Ease of Installation: Auto Program Naming,
Automat
ic Channel Install(ACI), Automatic Tuning
System (ATS), Autostore, Fine Tuning, PLL Digital
Tuning, Plug & Play
• Ease of Use: 4 favorite lists, Auto Volume Leveller
(AVL
), Delt
a Volume per preset, Graphical User
Interface, On Screen Display, Program List,
Settings assistant Wizard, Side Control
• Electronic Program Guide: Now + Next EPG, 8
day Electronic Progr
am Gu
ide
• Picture in Picture: Text dual screen
• Remote Control: TV
• Remote control type: RCPF03E08B
• Screen Format Adjustments: 4:3, Auto Format,
Mo
vie expand 14:9, Mo
vie expand 16:9, Subtitle
Zoom, Super Zoom, Widescreen
• Teletext: 1200 page Hypertext
• Teletext enhancements: 4 favourite pages,
Program info
rmatio
n Line
• Smart mode: Movie, Standard, Vivid
Multimedia Applications
• Multimedia connections: USB
• Playback Formats: MP3, Slideshow files (.alb), JPEG
Still pict
ures
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL I, PAL B/G, PAL
D/K, SECAM B/G,
SECAM D/
K, SECAM L/L', DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• Digital TV: DVB Terrestrial *
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Ext 2 Scart: Audio L/R, CVBS in/out, RGB
• Ext 3: YPbPr, Audio L/R in
• Ext 4: HDMI v1.3
• Ext 5: HDMI v1.3
• Ext 6: HDMI v1.3
• EasyLink (HDMI-CEC): One touch play, System
st
andb
y
• Front / Side connections: HDMI v1.3, S-video in,
CVBS in, Audio L
/R in, Headphone Out, USB
• Other connections: Analog audio Left/Right out,
PC Audi
o in, S/PDIF out (coaxial), Common
Interface
Power
• Ambient temperature: 5 °C to 35 °C
• Mains power: 220 - 240V, 50/60Hz
• Power consumption: 210 W
• Standby power consumption: 0.15 W
Dimensions
•Set dimensions (W x H x D):
1046 x 644 x 111 mm
• Set dimensions with stand (W x H x D):
1046
x
716 x 262 mm
• Weight incl. Packaging: 42 kg
• Product weight: 22.5 kg
• Product weight (+stand): 27 kg
•Box dimensions (W x H x D):
11
51
x 793 x 333 mm
• VESA wall mount compatible: 400 x 400 mm
Accessories
• Included accessories: Power cord, Quick start
guide, User Manual, Warranty certificate, Remote
Control, Batteries for remote control
•
