HEAT RECOVERY AIR HANDLING UNITS

AIRVENTS

Rated air flow [m³/h] 3500 5000 6000 9000

EC fans

Phase/voltage [50/60Hz/VAC] 3~380/480

Power/current [kW/A] 2x1.15/3.6 2x1.33/4.25 2x2.65/8.5 2x2.65/8.5

Fan speed [min

-1

] 2400 1350 1700 1700

Perm. amb. temp. [°C] -35...+50

Motor protection IP54

Insulation class F

Filter exhaust/supply ePM1 70%/ePM1 70% (ISO 16890)-F7 (EN779)

Weight (net, without packing) [kg] 420 628 628 1400

Housing protection class IP34

Sound pressure lvl @ 3m to environment [dBA] 35 32 32 32

Transported air temperature [°C] -25...+40

Dimensions [mm]

L W H H1 S1

CFH 800 1550 800 820 Ø315 -

CFH 1200 1550 800 820 Ø315 -

CFH 1500 1880 750 960 350 600

CFH 2500 1880 750 960 350 600

CFH 3500 2200 890 1290 400 700

CFH 5000 2300 1390 1420 500 1000

CFH 6000 2300 1390 1420 500 1000

CFH 9000 2990 2310 1710 600 1200

CFH

800 1200 1500 2500 3500 5000 6000 9000

Water heater

HW -2 L [mm] 360 360 360 360 360 360 360 360

Water cooler

CW-3 L [mm] 505 505 505 505 505 505 505 505

Electric heater

HE L [mm] 306 306 220 220 220 360 360 505

DX cooler

CDX-3 L [mm] 505 505 505 505 505 505 505 505

Additional coil sections for CFH 800-9000

Overall dimensions
