9
English
EN
3 On your TV, turn on HDMI-CEC operations.
For details, see the TV user manual.
• HDMI-CEC is a feature that enables
CEC compliant devices that are
connected through HDMI controlled
by a single remote control, such as
volume control for both the TV and
the home theater.
4 If you cannot hear the TV audio through
your home theater, set up the audio
manually.
Note
• If your TV has a DVI connector, you can use an HDMI/
DVI adapter to connect to TV. However, some of the
features may not be available.
Option 3: Connect to the TV through
composite video
Basic quality video
If your TV does not have HDMI connectors, use
a composite video connection. A composite
connectiondoesnotsupporthigh-denitionvideo.
1 Using a composite video cable, connect
the VIDEO (VIDEO OUT) connector
on your home theater to the VIDEO IN
connector on the TV.
• The composite video connector might
be labeled AV IN, COMPOSITE, or
BASEBAND.
TV
2 Connect an audio cable to hear the TV
audio through your home theater.
3 While you watch TV programs, press
SOURCE on your home theater
repeatedly to select the correct audio
input.
4 While you watch TV videos, switch your TV
to the correct video input. For details, see
the TV user manual.
Connect power
Caution
• Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back
or the underside of the unit.
• Risk of electric shock! When you unplug the AC power
cord, always pull the plug from the socket. Never pull
the cord.
• Before you connect the AC power cord, ensure that
you have completed all other connections.
