MEASUREMENT FOUNDATION

ROBOT 40

Selecting Units

Press and hold the button (3) for 2 sec. until the desired unit is displayed.

Illumination

Press and hold the button (4) for 2 seconds to switch the illumination on or off.

Clear-Key

Cancel the last action. Press button (5).

MEASUREMENTS

Single distance measurement

Press button (1) to activate the laser. When in continuous laser mode, press this button to trigger the distance measurement directly.

Press again to trigger the distance measurement. The result is displayed immediately.

Continuous Measurement

Press and hold the button (1) for about 2 seconds to start continuous measuring.

FUNCTIONS

Addition / Subtraction

Distance measuring.

Press button (3): next measurement is added to the previous one.

Press button (3): next measurement is substracted from the previous one.

The result is displayed in the second line. Previous value is displayed in the rst line.
