14 15
.........................440 W
............4000-10000 min
-1
....................3,2/6,4 mm (1/8"/1/4")
......................ø 150 mm
..........................2,8 kg
...........................86 dB (A)
...........................97 dB (A)
..........................8,5 m/s
2
..........................1,5 m/s
2
ENGLISH
ENGLISH
TECHNICAL DATA
Rated input ..............................................................................
No-load speed .........................................................................
Orbital travel diameter .............................................................
Dimensions of grinding plate ...................................................
Weight without cable ...............................................................
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) .......................................
Sound power level (K = 3 dB(A)) ............................................
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
Vibration emission value a
h
...................................................
Uncertainty K= ......................................................................
WARNING! Read all safety warnings and all
instructions, including those given in the accompanying
brochure. Failure to follow the warnings and instructions
may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause hearing
loss.
Use auxiliary handles supplied with the tool. Loss of
control can cause personal injury.
Appliances used at many different locations including open
air must be connected via a residual current device (FI,
RCD, PRCD).
Always wear goggles when using the machine. It is
recommended to wear gloves, sturdy non slipping shoes
and apron.
Always disconnect the plug from the socket before carrying
out any work on the machine.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.
Always lead the cable away behind you.
Before use check machine, cable, and plug for any
damages or material fatigue. Repairs should only be carried
out by authorised Service Agents.
The dust produced when using this tool may be harmful to
health (e.g. when working oak or beech wood, stones, paint,
which could contain lead or other harmful chemicals). Do
not inhale the dust. Use a dust absorption system and wear
a suitable dust protection mask. Remove deposited dust
thoroughly, e.g. with a vacuum cleaner.
Do not use machines on any material containing asbestos.
This machine is suitable only for dry sanding.
SPECIFIED CONDITIONS OF USE
This random orbital sander is a versatile machine. The
following work can be carried out with it: Coarse sanding
and grinding, Fine sanding and polishing, Rubbing down
weather-beaten paint, Polishing up scratches on acrylic
glass, Etc.
To provide the best adhesion, it is recommended that you
clean the backing pad and the sanding disc backing
occasionally by brushing them lightly with a small brush.
Do not use this product in any other way as stated for
normal use.
MAINS CONNECTION
Connect only to single-phase AC current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is
in conformity with the following standards or standardized
documents. EN 60745, EN 55014-1, EN 55014-2,
EN 61000-3-2, EN 61000-3-3, in accordance with the
regulations 98/37/EC, 2004/108/EC
Rainer Kumpf
Manager Product Development
Winnenden, 2009-01-15
ADVICE FOR OPERATION
Only use original AEG sanding and polishing tools with self-
adhesive velcro fastening.
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration emission may differ. This may signicantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all
times.
Use only AEG accessories and spare parts. Should
components need to be replaced which have not been
described, please contact one of our service agents (see
our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the Article No. as well as the machine type
printed on the label and order the drawing at your local
service agents or directly at: AEG Elektrowerkzeuge,
Max-Eyth-Straße 10, D-71364 Winnenden, Germany.
SYMBOLS
Please read the instructions carefully before
starting the machine.
Always disconnect the plug from the socket
before carrying out any work on the
machine.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste
electrical and electronic equipment and its
implementation in accordance with national
law, electric tools that have reached the end
of their life must be collected separately and
returned to an environmentally compatible
recycling facility.
