AEG MH 5 Е 412361 [10/37] English

18 19

MH 5 E KH 5 E

.......................1200 W .........................1200 W

.........................600 W ...........................600 W

............................... ..............................450 min

-1

............................... ..............................450 min

-1

.......................2840 min

.....................2840 min

..........................6,2 kg ............................6,6 kg

............................... ................................96 dB (A)

............................... ..............................107 dB (A)

...........................91 dB (A)

.........................101 dB (A)

.........................104 dB (A)

............................... ................................13 m/s

2

............................... ...............................1,5 m/s

2

ENGLISH

TECHNICAL DATA

Rated input ..............................................................................

Output ......................................................................................

No-load speed .........................................................................

Speed under load max. ...........................................................

Rate of percussion under load max. ........................................

Weight without cable ...............................................................

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (K = 3 dB(A)) .......................................

Sound power level (K = 3 dB(A)) ............................................

Wear ear protectors!

Noise Information MH 5 E

Typically the A-weighted sound pressure level of the

tool is .......................................................................................

Measured values determined according to 2000/14/EG at the

user’s ear.

2000/14/EC: Conformity assessment procedure according to

Annex VI. Notied Body:

VDE Testing and Certication Institute, Merianstr. 28,

Measured sound power level ................................................

Guaranteed sound power level .............................................

h

Hammer-drilling in concrete: vibration emission value a

Uncertainty K = .......................................................................

Chiselling: vibration emission value a

Uncertainty K = .......................................................................

SAFETY INSTRUCTIONS

Please pay attention to the safety instructions in the

attached leaet!

may contact hidden wiring or its own cord. Cutting

accessory contacting a „live“ wire may make exposed metal

parts of the power tool „live“ and shock the operator.

Appliances used at many different locations including open

air should be connected via a residual current device of

30 mA or less.

Always wear goggles when using the machine. It is

recommended to wear gloves, sturdy non slipping shoes

and apron.

Sawdust and splinters must not be removed while the

The vibration emission level will vary because of the ways in which a power tool can be used and may increase above the

level given in this information sheet. This could lead to a signicant underestimate of exposure when the tool is used regularly

in such a way.

Note: To be accurate, an estimation of the level of ex-posure to vibration experienced during a given period of work should

also take into account the times when the tool is switched off and when it is running but not actually doing the job. This may

signicantly reduce the exposure level over the total working period.

ENGLISH

SPECIFIED CONDITIONS OF USE

KH 5 E: The pneumatic hammer can be universally used for

hammer drilling and chiselling in stone and concrete.

MH 5 E: The hammer can be used for chiselling in stone

and concrete.

Do not use this product in any other way as stated for

normal use.

Rainer Kumpf

Manager Product Development

Winnenden, 2007-05-02

MAINS CONNECTION

Connect only to single-phase a.c. current and only to the

system voltage indicated on the rating plate. It is also

possible to connect to sockets without an earthing contact

as the design conforms to safety class II.

MAINTENANCE

The ventilation slots of the machine must be kept clear at all

components need to be replaced which have not been

described, please contact one of our AEG service agents

(see our list of guarantee/service addresses).

If needed, an exploded view of the tool can be ordered.

Please state the Article No. as well as the machine type

printed on the label and order the drawing at your local

service agents or directly at: AEG Elektrowerkzeuge,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

SYMBOLS

Please read the instructions carefully before

starting the machine.

Always disconnect the plug from the socket

observance of European Directive 2002/96/

EC on waste electrical and electronic

equipment and its implementation in

accordance with national law, electric tools

that have reached the end of their life must

be collected separately and returned to an

environmentally compatible recycling

facility.
