Section 02 ENGINE
Subsection 07 (PTO HOUSING AND MAGNETO)
STATOR OUTPUT V
OLTAGE TEST
TEST ENGINE
SPEED
TERMINAL VOLTAGE (AC)
1and2
1and34000 RPM
2and3
Approx. 50 Vac
If voltage is lower than specification, carry out a
STATOR CONTINUITY TEST
and a
STATOR INSU-
LATION TEST
. See procedures in this subsection.
Stator Continuity Test
Disconnect the magneto wiring harness connec-
tor. This connector is located between the ECM
and the throttle body.
smr2009
-016-015_b
1. Magneto connector
2. ECM
3. Thrott
le body
Install the 3-PIN MAGNETO HARNESS ADAPTER
(P/N 529 036 016)
onto the magneto connector.
NOTE: D
o not connect the magneto harness
adapte
r to the vehicle harness connector.
Set multimeter to
.
Connect multimeter between each pair of YEL-
LOW wires.
smr2009-022-101_b
STATOR CONTINUITY TEST
1. Connect adapter to magneto stator connector
2. Leave vehicle harness disconnected
Read resistance.
STATOR CONT
INUITY TEST
TERMINAL
RESISTANCE @
20°C (68°F)
1and2
1and3
2and3
0.1 - 1
If any result is out of specification, replace stator.
Stator Insulation Test
Disconnect the magneto wiring harness connec-
tor.
smr20
09-016-015_b
1. Magneto connector
2. ECM
3. Throt
tle body
Install the 3-PIN MAGNETO HARNESS ADAPTER
(P/N 529 036 016)
onto the magneto connector.
NOTE:
Do not connect the magneto harness
adapt
er to the vehicle harness connector.
Set multimeter to
.
Connect multimeter between any YELLOW wire
and engine ground.
smr2009-022 79
