Section 05 ELECTRICAL SYSTEM
Subsection 01 (CONTROLLER AREA NETWORK (CAN))
TROUBLESHOOTING
DIAGNOSTIC TIPS
Check the fault codes using B.U.D.S. software as a first troubleshooting step. Refer to
MONITORING
SYSTEM/FAULT CODES
section.
CAN Communication Problems
The following chart gives some symptoms and behaviors relative to the CAN component in cause. The
list is not exhaustive, only the most significant items are given to help troubleshooting.
CAN FAULTY
WIRES (NO
COMMUNICATION)
VEHICLE BEHAVIOR OR OBSERVATION
IN INFORMATION CENTER
OBSERVATION IN B.U.D.S.
Short circuit in CAN
wires
Engine is se
t to limp home mode.
iBR gate will not move. "Locked" in neutral.
iBR light is ON.
Check engi
ne light is ON.
B.U.D.S. will not be able to communicate
with any electronic module.
No vehicle detected message will be
displayed in B.U.D.S.
Informati
on center
(cluster)
Check engine light is ON.
iBR light is ON.
Some functions not displayed
such as: iS, VTS, RPM.
3 modules instead of 4 will be active.
"Cluster"
tab and its data will not be present.
ECM, iBR and iS will report a cluster CAN
problem.
ECM (Engin
e
Control Module)
Engine is set to limp home mode.
Check engine light is ON.
iBR light is ON.
iBR gate "locked" in neutral.
Some functions not displayed such as:
engine hours, RPM.
3 modules instead of 4 will be active.
ECM tab and its data will not be present.
iBR and iS will report an ECM CAN problem.
iBR (intelligent
Brake and Reverse)
Engine is set to limp home mode.
iBR gate will not move. "Locked" in neutral.
iBR light is ON.
Check engine light is ON.
Some functions not displayed
such as: Lake water temperature, no VTS,
no F,N,R indication.
3 modules instead of 4 will be active.
iBR tab and its data will not be present.
ECM and iS will report an iBR CAN problem.
iS (intelligent
Suspension)
iS handlebar controls have no effect.
No DOCK mode. Suspension will remain
to its last position before the CAN problem.
iS position is not displayed.
3 modules instead of 4 will be active.
iS tab a
nd its data will not be present.
Depth sounder
The menu Depth Sounder
Indicator will not be visible.
The Depth menu will not be available.
Nothing will be observable.
Diagnostic
conne
ctor
Nothing will be observable.
B.U.D.S. will not be able to communicate
with any electronic module.
No vehicle detected message will be
displayed in B.U.D.S.
278 smr2009-048
