Section 05 ELECTRICAL SYSTEM
Subsection 05 (STARTING SYSTEM)
3. Discharged battery
- Check/recharge. Refer to CHARGING SYSTEM.
4. Defective START/STOP switch
-Check.
5. Battery connections
- Check/clean/tighten.
6. Poor/bad or corroded ground contacts (engine,
starter etc.)
- Check/clean/repair.
7. Starter solenoid
-Check.
8. Starter malfunction
-Check.
9. Obstructed starter drive gear assembly
- Check/repair, refer to PTO HOUSING AND MAG-
NETO.
ENGINE CRANKS SLOWLY
1. Loose battery cables
- Check/clean/tighten.
2. Discharged/weak battery
- Check/charge/replace. Refer to CHARGING SYS-
TEM.
3. Worn starter
- Check, refer to STARTING SYSTEM.
STARTERDOESNOTTURN
1. 2 short beeps are not heard when pressing the
START/STOP button
- Refer to DIGITALLY ENCODED SECURITY SYS-
TEM.
2. Burnt fuse
- Check wiring condition and replace fuse.
3. Poor contact of battery terminal(s)
- Clean and tighten terminal(s).
4. Poor battery ground cable connection
- Clean and tighten.
5. Weak battery
- Recharge or replace battery.
6. Poor contact of START/STOP switch or solenoid
- Check connectors and clean contacts. Check and
replace defective parts.
7. Open circuit: START/STOP switch or solenoid
- Check. Replace if necessary.
STARTER TURNS, BUT STARTER DRIVE
DOES NOT MESH WITH RING GEAR
1. Worn starter drive gear
- Replace starter drive. Refer to PTO HOUSING
AND MAGNETO.
2. Defective drive
- Replace starter drive. Refer to PTO HOUSING
AND MAGNETO.
3. Poor movement of drive on splines
- Clean and correct. Refer to PTO HOUSING AND
MAGNETO.
4. Worn starter drive bushing
- Replace clutch. Refer to PTO HOUSING AND
MAGNETO.
5. Worn ring gear
- Replace ring gear. Refer to PTO HOUSING AND
MAGNETO.
STARTER KEEPS RUNNING
1. Shorted solenoid winding
- Replace solenoid.
2. Melted solenoid contacts
- Replace solenoid.
3. Sticking or defective starter drive
- Lubricate or replace. Refer to PTO HOUSING
AND MAGNETO.
PROCEDURES
WARNING
When carrying out any kind of maintenance
on the starting system, always disconnect the
battery ground cable. This will eliminate the
possibility of shorting out a power cable, and
generating a spark which could result in a fire
or and explosion. Do not place tools on the
battery.
STAR
TER SOLENOID FUSE
Check starter solenoid fuse (F4) condition in fuse
box 1. If it is burnt, it can be quickly identified by
the following symptoms:
The i
nformation center will come on and turn
off
after 5 seconds.
A fault code will be set.
Engine will not crank when pressing the
START/STOP button.
314 smr2009-034
