Section 05 ELECTRICAL SYSTEM
Subsection 05 (STARTING SYSTEM)
smr2009-034-002_c
1. Fuse box 2
Solenoid Input Voltage Test
(at Solenoid Connector)
Disconnect solenoid connector.
smr2009-034-007_a
1. Soleno
id connector
Install D.E.S.S. key.
Press t
he START/STOP button to activate ECM.
Use the
FLUKE 115 MULTIMETER (P/N 529 035 868)
andselect Vdc.
Measure voltage as per following table.
SOLENOID INPUT VOLTAGE TEST
(SOLENOID CONNECTOR)
TEST PROBES
VOLTAGE
READI
NG
Pin A
Battery
groun
d
Battery
volta
ge
smr2009-034-006_a
If test succ
eeded, carry out a
SOLENOID CON-
TROL CIRCUI
T TEST
.
If test failed, carry out a
POWER CIRCUIT TEST
as follows.
Solenoid P
ower Circuit Test
Remove relay in fuse box 2.
Set multimeter to
.
Test contin
uity of wiring as per following table.
SOLENOID POWER CIRCUIT TEST
SOLENOID
CONNECTOR
FUSE BOX 2
TERMINAL
RESISTANCE
Pin A A10
Closeto0
(continuity)
smr2009
-034-006_b
If test failed, repair or replace wiring/connectors.
If test s
ucceeded, power circuit is functional.
Solenoid Control Circuit Test
Use the F
LUKE 115 MULTIMETER (P/N 529 035 868)
and sele
ct
.
Disconnect the B connector from ECM.
Install
ECM ADAPTER TOOL (P/N 529 036 166) on
ECM connector.
Test con
tinuity of wiring as per following table.
318 smr2009-034
