Section 05 ELECTRICAL SYSTEM
Subsection 06 (DIGITALLY ENCODED SECURITY SYSTEM (D.E.S.S.))
MAXIMUM WATERC
RAFT SET SPEED TABLE
D.E.S.S. KEY
TYPE
KEY SETTING
APPROX.
MAX. SPEED
5
58 km/h
(36 MPH)
4
55 km/h
(34 MPH)
3
50 km/h
(31 MPH)
2
47 km/h
(29 MPH)
Learning key
1
42 km/h
(26 MPH)
5
74 km/h
(46 MPH)
4
69 km/h
(43 MPH)
3
63 km/h
(39 MPH)
2
58 km/h
(36 MPH)
Rental key
1
51 km/h
(32 MPH)
NOTE: The table indicates the approximate maxi-
mum speed given the type of key used. Depend-
ing on riding and environment conditions, the
given values can vary. At high altitude, variations
could be greater if impeller is not replaced.
BEEPER
Beeper Troubleshooting
If no beep is heard when installing the D.E.S.S.
key on the post and engine can be started, refer
to
GAUGE
to check the beeper operation.
If no beep is heard when installing the D.E.S.S.
key on the post and engine can NOT be started,
refer to
ELECTRONIC FUEL INJECTION
.
D.E.S.S. POST
D.E.S.S. Post Continuity Test
NOTE: For the following tests, the DIAGNOSTIC
HARNESS (P/N 529 036 179)
can be used to make an
in-line connection between the disconnected con-
nectors.
529036179
NOTE: Plug only the connector that has been dis-
connected.
smr2009-030-033_d
Use the FLUKE 115 MULTIMETER (P/N 529 035 868).
529035868_a
Open front storage cover.
Remove storage tray.
D.E.S.S. Key Removed from Post
From under the moving deck steering area, dis-
connect the 8-pin connector attached to the
D.E.S.S. post harness.
330 smr2009-035
