Section 05 ELECTRICAL SYSTEM
Subsection 07 (GAUGE)
Gauge Description
136
1
9
3
7
8
2
4
4
14121110
5
smo2009-
002-119_a
1. Speedometer
2. Tachometer
3. Digital
screen
4. Indicator lights
5. Fuel level
6. VTS posi
tion
7. iS position
8. Numerical display
9. Multif
unction display
10.Depth sounder indicator
11.Water temperature display
12.Hour me
ter display
13.iBR position
14.Compass
1) Speedometer
The sp
eedometer, located in the LH side of the
infor
mation center, provides an analog indication
of the
speed of the watercraft in miles per hour
(MPH)
and kilometers per hour (km/h).
The speed indication is based on a GPS (Global Po-
sitioning System) incorporated within the informa-
tion center.
An indicator light seen in the tachometer lights
up when the GPS is receiving a good signal. See
COMPASS
for illustration.
If fo
r some reason the GPS signal is lost, a de-
faul
t mode is used whereby, the speed is calcu-
late
d using information received from other sys-
tems
to provide an estimated watercraft speed.
2) Tachometer
The ta
chometer provides an analog indication of
the re
volutions per minute (RPM) of the engine.
Multi
ply the indicated number by 1000 to obtain
the ac
tual engine RPM.
3) Digital Screen
The digital screen, located in the center of the in-
formation center, is capable of providing 10 sepa-
rate indications simultaneously.
– Fuel level
–VTSp
osition
–iSdisplay
– Numerical display
– Mult
ifunction display
– Water temperature
– Engine hourmeter
–iBR
position
– Compass active indicator
– Depth sounder indicator.
smr2009-036 335
