Section 06 STEERING AND PROPULSION
Subsection 03 (JET PUMP)
3. Install impeller cover by aligning the cover index
mark with the pump top fin as shown.
sdd2009-001-114_c
1. Align mark
with top fin
NOTE: Cover can only be installed in one position
as screw holes are not located symmetrically.
4. Secure cov
er with NEW self-locking screws.
NOTE: Push cover against pump housing while
alternately tightening screws. Make sure O-rings
are positioned correctly and they are not damaged
when pushing the cover.
5. Torque cover screws to 7.5 N•m (66 lbf•in).
6. Perform
aleaktest. Referto
LEAK TEST
in this
subsect
ion.
IMPELLE
R
Impeller Removal
NOTE: If
impeller shaft is to be disassembled,
loosen t
he impeller shaft nut prior to removing
the impe
ller.
1. Remove jet pump from the watercraft. Refer to
JET PUMP HOUSING
in this subsection.
2. Remove impeller cover. Refer to
IMPELLER
COVER
in this subsection.
3. Remove
impeller boot by turning it clockwise
(LH thr
eads).
F19J06A
1
TYPICAL
1. Unscrew clockwise
4. Mount the flat sides of impeller shaft in a vise.
smr2009-006-005_a
TYPIC
AL
1. Flat side
5. Mount in the impeller splines the appropriate
impeller remover/installer tool according to en-
gine type.
MODEL TOOL
130 and 155
engines
IMPELLER
REMO
VER/INSTALLER
(P/N 529 035 820)
215
and 255
engines
IMPELLER
REMOVER/INSTALLER
(P/
N 529 035 956)
416 smr2009-039
