TV Operation

1. To switch on a suited video color system and a suited TV accompanying sound system

In TV mode, short press the BAND button repeatedly to switch on a suited video color system of the 5 ones

of the unit: PAL, SECAM, PAL M, PAL N, NTSC. If your monitor has only NTSC or PAL system, the monitor

screen will blink or become colorless when a not suited video color system of the unit is switched on. In one

of the above 5 video color systems, long press the BAND button repeatedly to switch on a suited TV

accompanying sound system of the unit for the selected video color system: PAL(PAL-DK, PAL-BG, PAL-I);

SECAM(SECAM-BG, SECAM-DK); PAL M (PAL M); PAL N(PAL N); NTSC(NTSC MN). If you switch on a not

suited TV accompanying sound system of the unit for the monitor, it cannot output sound.

2. To search and save (a) TV station(s)

In TV mode, short press the APS button, it will search a available TV station from the current frequency to

the high frequency. After searched a available TV station, it will stop searching and output the signal of the

available TV station and the available TV station will be saved in the channel.

In TV mode, long press the APS button, it will search all available TV stations from the lowest frequency to

the highest frequency. After searched for a circle, it will stop searching and output the signal of the

available TV station with the lowest frequency and all the available TV stations from the lowest frequency to

the highest frequency will be saved in the channels from 1 to 95.

3. To select a desired channel with an available TV station with UP/DN or / buttons on the remote

controller. In TV mode, short press the UP/DN button on the front panel or the /button on the remote

controller to select all TV channels. After Long pressing the APS button to search for a circle, short press the

UP/DN button on the front panel or the / button on the remote controller to select the desired channels

with available TV stations.

4. To select a desired channel with the number buttons

In TV mode, press one of the 10 buttons (1-10) to directly select the channel.

In TV mode, to directly select a channel more than 10, firstly press the 10+ button to display__, then input

the digit in tens place and then input the digit in units place with the 10 buttons (1-10).

5. To fine the TV signal

In TV mode, press and hold the UP/DN button on the front panel or the / button on the remote

controller to fine the TV signal of the current TV station. It can improve the quality of video and audio about

the TV program.

6. To save the current TV station in one of the channels from 1 to 6

In TV mode, long press one of the 1-6 buttons on the front panel, it will save the current TV station in the

number channel.
