18
4. Technical Specications
234E5QSB:
Power
On Mode 27.7W(typ.)
Sleep (typ.) 0.5W
Off (typ.) 0.3W
Power LED indicator On mode: White, Standby/Sleep mode: White (blinking)
Power Supply
External, 100-240VAC, 50-60Hz
234E5QHAB, 234E5QHAW:
Power
On Mode 29.1W(typ.), 41.4W(max.)
Sleep (typ.) 0.5W
Off (typ.) 0.3W
Power LED indicator On mode: White, Standby/Sleep mode: White (blinking)
Power Supply External, 100-240VAC, 50-60Hz
234E5QHSB, 234E5QHSW:
Power
On Mode 28.4W(typ.)
Sleep (typ.) 0.5W
Off (typ.) 0.3W
Power LED indicator On mode: White, Standby/Sleep mode: White (blinking)
Power Supply External, 100-240VAC, 50-60Hz
Dimension
Product with stand (WxHxD) 532 x 414 x 213 mm
Product without stand
(WxHxD)
532 x 325 x 45 mm
Weight
Product with stand 3.46 kg
Product without stand 3.11 kg
Product with packaging 5.09 kg
Operating Condition
Temperature range (operation) 0°C to 40 °C
Temperature range
(Non-operation)
-20°C to 60°C
Relative humidity 20% to 80%
MTBF 30,000hrs
Environmental
ROHS YES
