2. Setting up the monitor

2.1 Installation

Package contents

234E5

VGA (optional)

AC/DC Adapter

Audio cable (optional)

DVI (optional)

Cable management

Note

Use only the AC/DC adapter model: Philips

ADPC1945(234E5QSB/QHSB/QHSW),

ADPC1965(234E5QHAB/QHAW)

Install base stand

1. Place the monitor face down on soft

and smooth surface taking care to avoid

scratching or damaging the screen.

2. Hold the base stand with both hands and

firmly insert the base stand into the base

column.

(1) Gently attach the base to the base

column until the latch locks the base.

(2) Use your fingers to tighten the screw

located at the bottom of the base, and

secure the base to the column tightly.
