Trendnet TE-16PNP [4/5] Led indicators
![Trendnet TE-16PNP [4/5] Led indicators](/views2/1013077/page4/bg4.png)
Setup Program
This program comes in a diskette with the adapter package. To run, type the following at the
DOS prompt
> A:\UTILITY\TE16PNP
The main menu appears with the following options:
•
Setup Configuration. Lets you specify the connector type, I/O base address, interrupt
number, boot ROM starting address, and whether or not to enable the remote boot function.
For a list of the various supported settings, see Specifications.
•
Run Diagnostics. Lets you perform a diagnostic test on your adapter.
When configuring multiple adapters, ensure to assign a different I/O base address and interrupt
number for each. Also, reboot your computer after saving a new configuration to allow the new
configuration to be loaded into the system memory.
Note: If data in the EEPROM have been corrupted, setup would not be able to configure the
adapter. If this occurs, type the following at the DOS prompt
> A:\UTILITY\TE16PNP /I
This command restores the data in the EEPROM, thus allowing configuration of the adapter.
LED Indicators
The LED indicators help you monitor the network status. They are arranged in a row and are
located on the same side as the connectors(s). The following describes the function of each:
Power/Tx
Connector Used State Description
UTP/BNC ON There is power
Link/Rx
Connector Used State Description
UTP/BNC ON There is link
between port &
node
Supported Network Drivers
