![Irit IR-5559 [2/4] Ir 5559 ir 5559](/views2/1131094/page2/bg2.png)
IR-5559 IR-5559
2
3
Description
1. hopper plate
2. body
3. ON/OFF (switch)
4. fasten knob
5. Food pusher
6. Head
7. Cutting plate(fine)
8. Cutting plate(medium
9. Snake
10. Fixing ring
11. Cutting blade
12. Cutting plate(large)
13. Sausage attachment
14. Kibbe attachment
15. Head inlet
IMPORTANT SAFEGUARDS
Home use only. Do not use for industrial purpose.
Unplug when assembling and disassembling the unit.
Close supervision is necessary when any appliance is used near children.
When carrying the unit be sure to hold the body with both hands. Do not carry the unit by
the hopper plate or head.
Never push products by hand. Use food pusher.
Do not grind hard food such as bones, nuts, etc.
Do not grind ginger and other materials with hard fiber.
Continuous running of meat grinder should be not more than 10 minutes with the following
10minutes interval for motor cooling.
To avoid jamming, do not force to operate the unit with excessive pressure.
Never try to replace the parts and repair the unit by yourself.
This appliance is not intended for use by persons(including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety
Children should be supervised to ensure that they do not play with the appliance.
Do not operate this appliance if the cord or plug is damaged.
Do not try to repair the power cord by yourself.
FOR THE FIRST TIME
Wash all parts (except body) in warm soapy water, than clean with a dry cloth.
Locate the unit on a firm place. Before plug in, ensure the ON/0FF/R switch is in "0FF"
position.
Cut all food into pieces (boneless and fatless meat is recommended, approximate size: 20
mm x 20 mm x 60 mm) so that they fit easily into the
hopper opening.
Insert food through the hopper plate, using food pusher.
Plug the unit on and switch ON/0FF/R knob to "ON" position.
To avoid jamming, do not force to operate the unit with
excessive pressure.
After use switch the unit off and unplug it from the power supply.
Wash all parts (except body) in warm soapy water, than clean with a dry cloth
INSTRUCTION FOR USE
ASSEMBLING
Press the fasten button hold the head and insert it into the inlet (when inserting please pay
attention the head must be slanted as per arrow indicated on the top, see fig.1),then move
the head anticlockwise so that the head being fastened tightly .
Place the snake into the head, long end first, and turn to feed the screw slightly until
it is set into the motor housing .
Place the cutting blade onto the snake shaft with the blade facing the front as
illustrated. If it is not fitted properly, meat will not be grinded.
Place the desired cutting plate next to the cutting blade, fitting protrusions in the slot.
Support or press the centre of the cutting plate with one finger then screw the fixing
ring tight with another hand. Do not over tighten.
Place the hopper plate on the head and fix it into position.
Locate the unit on a firm place.
The air passage at the bottom and the side of the motor housing should be kept free and
not blocked.
REVERSE FUNCTION
In case of jamming switch off the appliance, position and ON/0/R switch to "R" position.
Snake will be rotating in the opposite direction, and the head will get empty.
If it doesn't work, switch off the unit and clean it.
MAKING SAUSAGE
Before starting please assemble sausage attachment as per following
CLEANING AND MAINTENACE
Remove meat, etc. Wash each part in warm soapy water.
A bleaching solution containing chlorine will discolor aluminum surfaces.
Do not immerse the motor housing in water, but only wipe it with a damp cloth.
Thinners and petrol will crack or change the color of the unit.
Wipe all the cutting parts with damp or wet cloth.
The importer retains his right to make changes in appearance and completeness of the
item without preliminary notification to the customer.
For household usage only.
Do not leave unattended!
Technical characteristics:
Power 500 W
Voltage 220V/50 Hz
Working life is 2 years
