4
Instruction manual
4
Headphone connection
• For private listening, insert 3.5 mm
headphone into the stereo headphone jack.
• Adjust volume control to the appropriate
level as desired.
• When the stereo headphone jack is
plugged, speaker will disconnect automatically.
Radio operation
• Press repeatedly MODE button until the
display shows FM.
• Press and hold
button or button;
the fast scanning starts. The frequency will
continue to change and will automatically stop
when a broadcast station is received.
• To receive a weak broadcast signal shortly
press
button or button and adjust the
frequency you wish to receive step-by-step.
Saving stations to memory
• In radio mode, press and hold PLAY/
PAUSE button, the unit will search and save all
available radio stations.
• Press PRE.+ or PRE.- to cycle through the
all saved stations.
Antenna
• For FM reception, adjust the telescopic
antenna appropriately to obtain the best
reception on the band selected.
USB/SD operations
Playback
• Turn on the device
• Insert a USB device into the USB port or
SD card into the slot. The unit will switch to
USB/SD mode automatically and the USB/SD
icon will show in the top of the display. Or, if
afterwards you selcted another mode, press
MODE button repeatedly to select USB/SD
mode.
• Playback of the first track will start
automatically. The display will show PLAY icon
in the top and the number of the track.
• Press PLAY/PAUSE button to pause
playback. Press the button again to resume
playback.
• Press repeatedly
button or button
to go to next or previous track. Press and
hold / buttons for backward or forward
searching; release the button for normal
playback.
• Press ALBUM+/ALBUM- buttons to select
next or previous albums or folders.
• Press and hold the MODE button once
to repeat the currently playing track. Press
and hold the MODE button twice to repeat the
whole album/folder.
General USB/SD notes
According to the USB 1.1/2.0 Standard,
usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.
Warning: usage of external USB drives
containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.
• This unit is equipped with a USB socket
that can accept and play MP3 files stored on
standard USB flash (2.0 version)/SD cards up
to 32 GB.
• FAT and FAT32 file system are supported
by this unit.
AUX jack
You can connect the audio output of an
external device to this unit, to listen to the sound
of that device through the speakers of this unit.
• To connect an external audio device,
please use a standard audio cable with 3.5-mm-
to-3.5 mm plugs (not included) to connect the
headphone out or audio line-out of the external
