Инструкция по эксплуатации Страница: 56

Yamaha S90ES [56/80] 2 receive flow

MIDI>-+-[SW10]--+---------NOTE OFF 8nH

| |

| +---------NOTE ON/OFF 9nH

| |

| +---------KEY'S AFTER TOUCH AnH (Seq only)

| |

| +---------CONTROL CHANGE (All in Seq)

| | MODULATION BnH,01H

| | PORTAMENTO TIME BnH,05H

| | DATA ENTRY MSB BnH,06H

| | DATA ENTRY LSB BnH,26H

| | MAIN VOLUME BnH,07H

| | PAN BnH,0AH

| | EXPRESSION BnH,0BH

| | SUSTAIN SWITCH BnH,40H

| | PORTAMENTO SWITCH BnH,41H

| | SOSTENUTO BnH,42H

| | HARMONIC CONTENT BnH,47H

| | EG RELEASE TIME BnH,48H

| | EG ATTACK TIME BnH,49H

| | BRIGHTNESS BnH,4AH

| | EG DECAY TIME BnH,4BH

| | EFFECT1 DEPTH BnH,5BH

| | EFFECT3 DEPTH BnH,5DH

| | DATA ENTRY INC BnH,60H

| | DATA ENTRY DEC BnH,61H

| | ALL SOUND OFF BnH,78H

| | ASSIGNABLE CONTROLLER BnH,(00H..5FH)

| | NRPN BnH,62H,63H *1

| | RPN

| | PITCH BEND SENS. BnH,64H,00H,65H,00H,06H,mmH

| | FINE TUNING BnH,64H,01H,65H,00H,06H,mmH,

| | 26H,llH

| | COARSE TUNING BnH,64H,02H,65H,00H,06H,mmH

| | RPN RESET BnH,64H,7FH,65H,7FH

| +--[SW2]--EG SUSTAIN LEVEL BnH,1FH

| |

| +--[SW7]--BANK SEL MSB BnH,00H

| | BANK SEL LSB BnH,20H

| |

| +---------CHANNEL MODE MESSAGE

| | RESET ALL CONTROLLERS BnH,79H

| | OMNI MODE OFF BnH,7CH

| | OMNI MODE ON BnH,7DH

| | MONO MODE ON BnH,7EH

| | POLY MODE ON BnH,7FH

| |

| +--[SW8]--PROGRAM CHANGE CnH

| |

| +---------CHANNEL AFTER TOUCH DnH

| |

| +---------PITCH BEND CHANGE EnH

+--[SW3]------------SYSTEM REALTIME MESSAGE

| TIMING CLOCK F8H

+--[SW4]------------SYSTEM REALTIME MESSAGE

| START FAH

| CONTINUE FBH

| STOP FCH

+-------------------ACTIVE SENSING FEH

+--[SW5]-+-----+----SYSTEM EXCLUSIVE MESSAGE (All in Seq)

| | MIDI MASTER VOLUME F0H 7FH 7FH 04H 01H llH mmH

| | F7H

| |

| +--[SW9]---<BULK DUMP>

| | F0H 43H 0nH 7FH 01H bhH blH ahH amH alH ddH...ddH ccH F7H *2

| |

| +--[SW6]---<PARAMETER CHANGE>

| | F0H 43H 1nH 7FH 01H ahH amH alH ddH...ddH F7H *2

| |

| +--[SW6]---<BULK DUMP REQUEST>

| | F0H 43H 2nH 7FH 01H ahH amH alH ddH...ddH F7H *2

| |

| +--[SW6]---<PARAMETER REQUEST>

| | F0H 43H 3nH 7FH 01H ahH amH alH F7H *2

| |

| +--[SW11]--XG SYSTEM ON

| | F0H 43H 1nH 4CH 00H 00H 7EH 00H F7H

| |

| +--[SW11]--GM MODE ON

| F0H 7EH 7FH 09H 01H F7H

+-------------------SYSTEM EXCLUSIVE MESSAGE

IDENTITY REQUEST F0H 7EH 0nH 06H 01H F7H

[SW2] MIDI Control Mode

[SW3] MIDI Sync (can be set to “internal” or “MIDI”)

[SW4] Seq MIDI Control

[SW5] MIDI Device Number

When this is not set to off, the MIDI Master Volume can be recognized in any mode.

[SW6] The System data can be transmitted/recognized in any mode.

Regarding the other types of data, it depends on the current mode whether they can be transmitted/recognized

or not.

[SW7] System Bank Select Switch

[SW8] System Program Change Switch

[SW9] System Bulk Protect and same as SW6.

[SW10] MIDI Receive Channel and Receive Filter

In the Multi mode: complies with Part Receive Channel and Part Receive Switch.

In the other mode: complies with Basic Receive Channel.

[SW11] SYSTEM Receive GM/XG On

(3-1-1) NOTE OFF

STATUS 1000nnnn(8nH) n = 0 – 15 CHANNEL NUMBER

NOTE No. 0kkkkkkk k = 0 (C-2) – 127 (G8)

VELOCITY 0vvvvvvv V: ignored

Receive only

(3-1-2) NOTE ON/OFF

STATUS 1001nnnn(9nH) n = 0 – 15 CHANNEL NUMBER

NOTE NUMBER 0kkkkkkk k = 0(C-2) – 127(G8)

VELOCITY NOTE ON 0vvvvvvv(v≠0)

NOTE OFF 0vvvvvvv(v=0)

(3-1-3) CONTROL CHANGE

STATUS 1011nnnn(BnH) n = 0 – 15 CHANNEL NUMBER

CONTROL NUMBER 0ccccccc

CONTROL VALUE 0vvvvvvv

*TRANSMITTED CONTROL NUMBER

c = 0 BANK SEL MSB ; v = 0 - 127 *3

c = 32 BANK SEL LSB ; v = 0 - 127 *3

c = 1 MODULATION ; v = 0 - 127

c = 7 MAIN VOLUME ; v = 0 - 127

c = 10 PAN ; v = 0 - 127

c = 11 EXPRESSION ; v = 0 - 127

c = 64 SUSTAIN SWITCH ; v = 0, 127

c = 71 FILTER RESONANCE ; v = 0:-64 - 64: 0 - 127:+63

c = 72 EG RELEASE TIME ; v = 0:-64 - 64: 0 - 127:+63

c = 73 EG ATTACK TIME ; v = 0:-64 - 64: 0 - 127:+63

c = 74 FILTER CUTOFF FREQ ; v = 0:-64 - 64: 0 - 127:+63

c = 75 EG DECAY TIME ; v = 0:-64 - 64: 0 - 127:+63

c = 91 REVERB SEND ; v = 0, 127

c = 93 CHORUS SEND ; v = 0, 127

c = 0..95 ASSIGNABLE CONTROLLERS ; v = 0 - 127 *6

The Sequencer Part will play back all recorded control change messages.

*RECEIVED CONTROL NUMBER

c = 0 BANK SEL MSB ; v = 0 - 127 *3

c = 32 BANK SEL LSB ; v = 0 - 127 *3

c = 1 MODULATION ; v = 0 - 127

c = 5 PORTAMENTO TIME ; v = 0 - 127 *2

c = 6 DATA ENTRY MSB ; v = 0 - 127 *1

c = 38 DATA ENTRY LSB ; v = 0 - 127 *1

c = 7 MAIN VOLUME ; v = 0 - 127

c = 10 PAN ; v = 0 - 127

c = 11 EXPRESSION ; v = 0 - 127

c = 31 EG SUSTAIN LEVEL ; v = 0:-64 - 64:0 - 127:+63 *2,*5

c = 64 SUSTAIN SWITCH ; v = 0 - 127 *2

c = 65 PORTAMENTO SWITCH ; v = 0 - 63:OFF, 64 - 127:ON *2

c = 66 SOSTENUTO ; v = 0 - 63:OFF, 64 - 127:ON *2

c = 71 HARMONIC CONTENT ; v = 0:-64 - 64:0 - 127:+63

c = 72 EG RELEASE TIME ; v = 0:-64 - 64:0 - 127:+63 *2

c = 73 EG ATTACK TIME ; v = 0:-64 - 64:0 - 127:+63

c = 74 BRIGHTNESS ; v = 0:-64 - 64:0 - 127:+63

c = 75 EG DECAY TIME ; v = 0:-64 - 64:0 - 127:+63

c = 91 EFFECT1 DEPTH ; v = 0 - 127

c = 93 EFFECT3 DEPTH ; v = 0 - 127

c = 96 DATA ENTRY INC ; v = 127 *1

c = 97 DATA ENTRY DEC ; v = 127 *1

c = 0..95 ASSIGNABLE CONTROLLER ; v = 0 - 127 *6

c = 0..95 ARPEGGIO SW ; v = 0 - 63:OFF, 64 - 127:ON *6

c = 0..95 ARPEGGIO HOLD ; v = 0 - 63:OFF, 64 - 127:ON *6

BREATH CONTROLLER 2

FOOT CONTROLLER 4

Assign 1 16

Assign 2 17

Assign A 18

Assign B 19

FOOT SWITCH 88

ARPEGGIO HOLD 89

ARPEGGIO SWITCH 90

CATEGORY MSB LSB PROGRAM No.

GM Voice 0 0 0..127 (1..128)

GM Drum Voice 127 0 0..1 (1..2)

Normal Voice Preset 1 63 0 0..127 (1..128)

Preset 2 63 1 0..127 (1..128)

Preset 3 63 2 0..127 (1..128)

Preset 4 63 3 0..127 (1..128)

User1 63 8 0..127 (1..128)

User2 63 9 0..127 (1..128)

Drum Voice Preset 63 32 0..63 (1..64)

User 63 40 0..31 (1..32)

Plug-in Voice User 1 63 24 0..63 (1..64)

User 2 63 25 0..63 (1..64)

User 3 63 26 0..63 (1..64)

Performance User 63 64 0..127 (1..128)

Multi User 63 65 0..63 (1..64)

Plug-in Voice Preset 1 (Slot1) 63 70 0..63 (1..64) *4

Preset 2 (Slot1) 63 71 0..63 (1..64) *4

Preset 3 (Slot1) 63 72 0..63 (1..64) *4

Preset 1 (Slot2) 63 73 0..63 (1..64) *4

Preset 2 (Slot2) 63 74 0..63 (1..64) *4

Preset 3 (Slot2) 63 75 0..63 (1..64) *4

Preset 1 (Slot3) 63 76 0..63 (1..64) *4

Preset 2 (Slot3) 63 77 0..63 (1..64) *4

Preset 3 (Slot3) 63 78 0..63 (1..64) *4

Перечень данных

Формат данных MIDI

(3) ПРИЕМ / ПЕРЕДАЧА ДАННЫХ

(3-1) СООБЩЕНИЯ ГОЛОСА КАНАЛА

*1: Доступно только для вставленных голосов.

*2: Распознается / передается только при выборе вставленного голоса CS6X (MODEL ID = 0x64).

(2) RECEIVE FLOW

*1 Используется только если значение установлено с помощью PRN.

*2 Не действует для голосов ударных инструментов.

*3 Между BANK CHANGE и PROGRAM установлены следующие соотношения:

*4 Может выбираться только в том случае, когда установлена соответствующая вставная панель.

* 5 Передается / принимается только при выборе варианта MODE2 для параметра Control Change Mode/

* 6 Исходные значения контрольных номеров для ASSIGNABLE CONTROLLER:
