Inotec NL3 [2/9] Parts list

Inotec NL3 [2/9] Parts list
ITEM QTY PART NO Paraong P/N DESCRIPTION CHINESE DESCRIPTION
1 1 52208PA-B P20-3022 PTD ASSY, LPD TOWER 主架固定管組
2 1 5298501-D P20-3028 ASSY, LPD MAIN FRAME 固定立管組
3 1 52219PA-A P20-3024 PTD ASSY, LPD LOWER FRAME CONNECTOR 連接管組
4 6 2006424 BOLT, 3/8-16 X 6-1/4" (159mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x 6-1/4"L
點耐落
5 8 2003001 WASHER, 3/8" SAE CURVED 弧形華司
6 30 2001101 WASHER, FLAT 3/8 SAE ST ZN 平面華司20X10.5X1.0T
7 6 2005410 BOLT, 3/8-16 X 2-3/4" (70mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 2-3/4"L
8 5 2005409 BOLT, 3/8-16 X 2-1/2" (64mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 2-1/2"L
9 15 2001201 NUT, 3/8-16 LK ST ZN 尼龍螺帽3/8"-16x11T
10 1 5219901-A P20-3024 WLDMT, LPD UPPER CONNECTOR 連接管組
11 2 5221401-A P02-4251 PLATE, 50 X 155 X 4MM 固定片
12 1 5218701-A P04-2820 WLDMT, KNEE HOLD DOWN 泡棉管組
13 1 52201PA-A P20-3026 PTD ASSY, LPD PULL ARM LFT 左高拉管組
14 1 52202PA-A P20-3025 PTD ASSY, LPD PULL ARM RHT 右高拉管組
15 2 5215901 P05-0979 CAP, AL END 6205Z BEARING HOUSING 鋁蓋
16 2 5215101-A P03-1947 SPACER, 25.5 ID X 31.8 OD X 20 套管
17 6 2006403 BOLT, 3/8-16 X 1" (25mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x 1"L
點耐落
18 2 5222501-B P03-1945 COUNTER WEIGHT, 325 LONG DIPPED 配重鐵心
19 1 5212601 P06-2151 COVER, TOWER BASE 塑膠底座
20 12 2004802 SCREW, 10-32 X 1/2" (12MM) PAN HEAD W/NP 大扁頭十字螺絲#10-32x1/2"L 點耐落
21 2 5209701 P01-3735 GUIDE ROD, 19 DIA X 1315 升降桿
22 15 52101PA P10-0778 PTD ASSY, 15 LB WEIGHT PLATE 選擇片
23 1 5250201-C P20-2989 ASSY, 15 PLATE HEAD PLATE 上片組
24 1 5218201-D P20-2988 ASSY, 7.5LB INC. WEIGHT 配重塊組
25 2 5098201 P06-0034 CUSHION, WEIGHT STACK 橡膠墊
26 2 5095301 A05-0212 SHAFT COLLAR, GUIDE ROD 固定軸套
27 2 5209801 P06-2144 BUSHING, GUIDE ROD RETAINER 升降桿護套
28 1 5224601-A P17-0009 BELT, TOWER 滑輪皮帶
29 1 52245PA-A P20-2991 PTD ASSY, BELT - 4.5 PULLEYS 90 DEG 輪座片組
30 2 5248501-A P08-0121 SPACER, FLNG 16.2 X 10.1 X 6 T帽套管
31 1 5248401-A P03-2026 SPACER, 16 OD X 10.1 ID X 36 套管
32 2 5208201-A P02-4266 PLATE, BELT CLAMP 固定片
33 1 5297701 LABEL, WEIGHT STACK 15LBS 磅數表
34 2 2005404 BOLT, 3/8-16 X 1-1/4" (32mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 1-1/4"L
35 1 5303901-A P13-0337 CABLE ASSY, LPD 連接鋼索
36 7 5094501-B P06-0961 PULLEY, 4-1/2 OD X 25 大滑輪
37 1 2005406 BOLT, 3/8-16 X 1-3/4" (45mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 1-3/4"L
38 1 2005407 BOLT, 3/8-16 X 2" (51mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 2"L
39 8 5214601-C P06-2135 COVER, PULLEY 152MM DIA 護蓋
40 8 5216301-A P08-0165 SPACER, FLNG 16.2 X 10.2 X 7.5 T帽套管
PARTS LIST
Page 2
