41 10 5214601-C P06-2135 COVER, PULLEY 152MM DIA 護蓋

42 10 5217601-A P06-2208 WASHER, RUBBER 19 ID X 25 OD X 3 墊片

43 10 5216301-A P08-0165 SPACER, FLNG 16.2 X 10.2 X 7.5 T帽套管

44 2 5224101-A PIN, 10 DIA X 35

45 2 2006410 BOLT, 3/8-16 X 2-3/4" (70mm) SOCKET HEAD W/NP

六角承窩螺絲 3/8"

x2 3/4"L 點耐落

46 2 5084101-A P06-0961 PULLEY, 4-1/2 OD X 1-1/2 V-GROOVE 大V滑輪

47 2 5335501-A PIN, 10 DIA X 48

48 2 2006412 BOLT, 3/8-16 X 3-1/4" (83mm) SOCKET HEAD W/NP

六角承窩螺絲 3/8"

x3 1/4"L 點耐落

49 2 5216401-A P05-0977 ROD END, M-12 FEMALE 關節軸承

50 2 2005701 NUT, M12 JAM ST ZN M12 螺帽

51 2 2006405 BOLT, 3/8-16 X 1-1/2" (38mm) SOCKET HEAD W/NP

六角承窩螺絲 3/8"

x1 1/2"L 點耐落

52 1 5297001-A P10-0783 ASSY, REAR SHROUD 后護網

53 1 5296201-A ASSY, SR PLACARD 塑膠蓋含運動看板

54 1 5294601-A P20-2990 ASSY, TOWER CAP 塑膠蓋組

55 2 5244001-A P06-2153 TRAY, TOWER CAP - LARGE 橡膠墊

56 1 5244101-A P06-2156 TRAY, TOWER CAP - SMALL 橡膠墊

57 1 5246601-A P07-0433 PAD, CHEST 胸墊

58 4 2006404 BOLT, 3/8-16 X 1-1/4" (32mm) SOCKET HEAD W/NP

六角承窩螺絲 3/8"

x1 1/4"L 點耐落

59 1 5246201-B P07-0434 PAD, SMALL SEAT 座墊

60 1 5248601-A P04-2854 SR TOWER WELDMENT 主架固定管

61 5223801-B P04-2813 PLATE, LIMIT 限位片組

62 4 5213001-A P06-2143 CUSHION, SHROUD HOLDER 緩衝墊

63 2 5293901-B P06-2254 FOOT, TOWER 腳墊

64 2 5203801-A A06-0231 BELT PULLEY 平皮帶滑輪

65 2 BOLT, 3/8-16 X 3-1/2" (89mm) SOCKET HEAD

六角承窩螺絲 3/8"

x 3-1/2"L

66 WASHER, FLAT 12 X 5.2 X1.0T 平面華司12X5.2X1.0T

67 8 AVK INSERT 拉帽

68 8 2006503 BOLT, 1/4-20 X 3/4" (19mm) SOCKET HEAD W/NP

六角承窩螺絲

1/4"x 3/4"L 點耐落

69 8 WASHER, FLAT 16 X 6.5 X 1.0T 平面華司16X6.5X1.0T

70 1 52319PA-C P20-3012A SUB ASSY, SR MAIN FRAME 固定立管組

71 1 5231901-C P04-2855 SR MAIN FRAME WELDMENT 固定立管

72 1 5205501-A P05-0962 ADJUSTMENT, SEAT 調整塊

73 1 P06-0134 PLUG 扣塞

74 1 5205401-A P06-2129 END CAP, FLATOVAL 橢圓管塞

75 2 5234301-B P06-2131 SLEEVE 中管塞

76 1 5214501-A P06-2141 COVER, PIVOT 固定座

77 1 5213101-B P06-2147 Main Frame Foot Pad 腳墊

78 2 5205601-A P06-2255 ADJUSTER, SP PRESS ARM 緩衝墊

79 1 5294101-A P06-2256 LEVELER 腳墊

80 4 P08-0048 BUSHING, 25.55X19.05X16 FLANGE BRONZE 含油軸承

81 1 5297801-B P11-0189 ADJUSTMENT PIN 彈簧插鞘組

82 2 NUT, 3/8-16 X 7.2T, LK ST ZN 尼龍螺帽3/8"-16x7.2T
