Inotec NL4 [2/10] Parts list

Inotec NL4 [2/10] Parts list
ITEM QTY PART NO Paraong P/N DESCRIPTION Chinese Description
1 1 5298301-D P20-3014 ASSY, SR MAIN FRAME 座墊調節管組
2 1 52486PA-A P20-3011 ASSY, SR TOWER 主架固定管組
3 1 52337PA-A P20-3015 PTD ASSY, SR-AB BASE CONNECTOR 連接管組
4 6 2003001 WASHER, 3/8" SAE CURVED 弧形華司
5 6 2006424 BOLT, 3/8-16 X 6-1/4" (159mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x 6-1/4"L 點耐落
6 30 2001101 WASHER, FLAT 3/8 SAE ST ZN 平面華司20X10.5X1.0T
7 4 2005410 BOLT, 3/8-16 X 2-3/4" (70mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 2-3/4"L
8 3 2005409 BOLT, 3/8-16 X 2-1/2" (64mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 2-1/2"L
9 11 2001201 NUT, 3/8-16 LK ST ZN 尼龍螺帽3/8"-16x11T
10 1 5233901-A P04-2856 WLDMT, SR-AB UPPER CONNECTOR 連接管組
11 1 5221401-A P02-4251 PLATE, 50 X 155 X 4MM 固定片
12 2 52329PA-A P20-3016 PTD ASSY, SR MAIN ARM 活動管組
13 2 5215101-A P03-1947 SPACER, 25.5 ID X 31.8 OD X 20 套管
14 2 5215901-B P05-0979 CAP, AL END 6205Z BEARING HOUSING 鋁蓋
15 6 2006403 BOLT, 3/8-16 X 1" (25mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x1"L 點耐落
16 2 5297401-B P20-3019 ASSY, SR SECONDARY ARM & SWIVEL HANDLE 活動把手組
17 1 5212601-C P06-2151 COVER, TOWER BASE 塑膠底座
18 12 2004802 SCREW, 10-32 X 1/2" (12MM) PAN HEAD W/NP 大扁頭十字螺絲#10-32x1/2"L 點耐落
19 2 5209701-A P01-3735 GUIDE ROD, 19 DIA X 1315 升降桿
20 15 52101PA-B P10-0778 PTD ASSY, 15 LB WEIGHT PLATE 選擇片
21 1 5250201-C P20-2989 ASSY, 15 PLATE HEAD PLATE 上片組
22 1 5218201-D P20-2988 ASSY, 7.5LB INC. WEIGHT 配重塊組
23 2 5209801-A P06-2144 BUSHING, GUIDE ROD RETAINER 升降桿護套
24 2 5095301-A A05-0212 SHAFT COLLAR, GUIDE ROD 固定軸套組
25 2 5098201-A P06-0034 CUSHION, WEIGHT STACK 緩衝墊
26 1 5224601-A P17-0009 BELT, TOWER 滑輪皮帶
27 1 52245PA-A P20-2991 PTD ASSY, BELT - 4.5 PULLEYS 90 DEG 輪座片組
28 2 5248501-A P08-0121 SPACER, FLNG 16.2 X 10.1 X 6 T帽套管
29 1 5248401-A P03-2026 SPACER, 16 OD X 10.1 ID X 36 套管
30 2 5208201-A P02-4266 PLATE, BELT CLAMP 固定片
31 1 5297701-A LABEL, WEIGHT STACK 15LBS 磅數表
32 2 2005404 BOLT, 3/8-16 X 1-1/4" (32mm) SOCKET HEAD
六角承窩螺絲 3/8"
x1 1/4"L
33 1 5304001-A P13-0296 CABLE ASSY, SR 低拉鋼索
34 5 5094501-B P06-0961 PULLEY, 4-1/2 X 25 大滑輪
35 1 2005406 BOLT, 3/8-16 X 1-3/4" (45mm) SOCKET HEAD
六角承窩螺絲 3/8"
x1 3/4"L
36 1 2005407 BOLT, 3/8-16 X 2" (51mm) SOCKET HEAD
六角承窩螺絲 3/8"
x2"L
37 1 5212901-B P10-0785 SHROUD, TOWER FRONT - LH 左前護網
38 1 5212801-B P10-0784 SHROUD, TOWER FRONT - RH 右前護網
39 4 5213201-B P06-2146 MOUNT, 19MM ID STANDOFF 橡膠墊
40 4 2005405 BOLT, 3/8-16 X 1-1/2" (38mm) SOCKET HEAD
六角承窩螺絲 3/8"
x1 1/2"L
Page 2
PARTS LIST
