ITEM QTY PART NO Paraong P/N DESCRIPTION Chinese Description
1 1 52039PA-B P20-3005 PTD ASSY, BC TOWER 主架固定管組
2 1 52042PA-A P20-3008 PTD ASSY, BC FRAME CONNECTOR 連接管組
3 1 5298601-C P20-3021 ASSY, BC FRAME 固定立管組
4 6 2003001 WASHER, 3/8" SAE CURVED 弧形華司
5 4 2006424 BOLT, 3/8-16 X 6-1/4" (159mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x 6-1/4"L 點耐落
6 29 2001101 WASHER, FLAT 3/8 SAE ST ZN 平面華司20X10.5X1.0T
7 5 2005409 BOLT, 3/8-16 X 2-1/2" (64mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 2-1/2"L
8 7 2001201 NUT, 3/8-16 LK ST ZN 尼龍螺帽3/8"-16x11T
9 2 2005410 BOLT, 3/8-16 X 2-3/4" (70mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 2-3/4"L
10 1 5206801-A P04-2851 WLDMT, BC PIVOT ARM SUPPORT 護片組
11 2 5207101-A P02-4281 PLATE, BACKING 連接片
12 1 52072PA-A P20-3010 PTD ASSY, BC PAD SUPPORT 連接管組
13 2 2006415 BOLT, 3/8-16 X 4" (102mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x 4"L 點耐落
14 5 2006404 BOLT, 3/8-16 X 1-1/4" (32mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x 1-1/4"L 點耐落
15 1 52075PA-A P20-3006 PTD ASSY, BC PIVOT ARM 擺臂管組
16 1 5298001-A P05-1208 CAP, AL END PIVOT POINT 鋁蓋
17 3 2006403 BOLT, 3/8-16 X 1" (25mm) SOCKET HEAD W/NP
六角承窩螺絲 3/8"
x 1"L 點耐落
18 1 52084PA-B P20-3007 PTD ASSY, BC HANDLE 把手管組
19 1 5208901-A P05-0981 CAP, AL END 鋁蓋
20 1 5234801-A P03-2019 BUSHING, STOP 套管
21 1 5212601-C P06-2151 COVER, TOWER BASE 塑膠底座
22 12 2004802 SCREW, 10-32 X 1/2" (12MM) PAN HEAD W/NP 大扁頭十字螺絲#10-32x1/2"L 點耐落
23 2 5209701-A P01-3735 GUIDE ROD, 19 DIA X 1315 升降桿
24 10 52101PA-B P10-0778 PTD ASSY, 15 LB WEIGHT PLATE 選擇片
25 1 5250101-C P20-2999 ASSY, 10 PLATE HEAD PLATE 上片組
26 1 5218201-D P20-2988 ASSY, 7.5LB INC. WEIGHT 配重塊組
27 2 5098201-A P06-0034 CUSHION, WEIGHT STACK 緩衝墊
28 2 5095301-A A05-0212 SHAFT COLLAR, GUIDE ROD 固定軸套組
29 2 5209801-A P06-2144 BUSHING, GUIDE ROD RETAINER 升降桿護套
30 1 5224701-B P17-0012 BELT, ESAC TOWER 滑輪皮帶
31 1 5209501-A P02-4387 PLATE, BELT WRAP 固定片
32 1 5208201-A P02-4266 PLATE, BELT CLAMP 固定片
33 2 2001201 NUT, 3/8-16 LH LK ST ZN 尼龍螺帽3/8"-16x7.2T
34 6 2005405 BOLT, 3/8-16 X 1-1/2" (38mm) SOCKET HEAD
六角承窩螺絲 3/8"
x 1-1/2"L
35 1 5248901-A P10-0807 SHROUD, TOWER FRONT N/O 右前護網
36 1 5212901-B P10-0785 SHROUD, TOWER FRONT - LH 左前護網
37 1 5297701-A LABEL, WEIGHT STACK 15LBS 磅數表
38 4 5213201-B P06-2146 MOUNT, 19MM ID STANDOFF 橡膠套
39 1 5297001-A P10-0783 ASSY, REAR SHROUD 后護網
40 1 5294601-A P20-2990 ASSY, TOWER CAP 塑膠蓋組
41 1 5295001-A ASSY, BC PLACARD 塑膠蓋含運動看板
Page 2
PARTS LIST
