Inotec NL18 [2/9] Parts list

ITEM QTY PART NO Paraong P/N DESCRIPTION Chinese Description

1 1 54252PA P20-4311 PTD ASSY, G BASE CONNECTOR 底管組

2 1 54259PA P20-4301 PTD ASSY, G FRONT UPRIGHT with Pad Adjustment 扶手管組+調整管組

3 1 54266PA P20-4302 PTD ASSY, G MAIN FRAME 固定管組

4 10 2003001 WASHER, 3/8" SAE CURVED 弧形華司 22x10x1.5t

5 2 2005425 BOLT, 3/8-16 X 6-1/2" (165mm) SOCKET HEAD 六角承窩螺絲 3/8" x 6 1/2"L

6 38 2001101 WASHER, FLAT 3/8 SAE ST ZN 平面華司 20 x 10.5 x 1.0t

7 6 2005409 BOLT, 3/8-16 X 2-1/2" (64mm) SOCKET HEAD 六角承窩螺絲 3/8" x 2 1/2"L

8 20 2001201 NUT, 3/8-16 LK ST ZN 尼龍螺帽 3/8"x11t

9 1 54255PA P20-4298 PTD ASSY, G FOOT PLATFORM 腳踏板組

10 2 2006407 BOLT, 3/8-16 X 2" (51mm) SOCKET HEAD W/NP 六角承窩螺絲 3/8" x 2"L 點耐落

11 1 54250PA P20-4297 PTD ASSY, G TOWER 主架固定管組

12 4 2005410 BOLT, 3/8-16 X 2-3/4" (70mm) SOCKET HEAD 六角承窩螺絲 3/8" x 2 3/4"L

13 6 2006424 BOLT, 3/8-16 X 6-1/4" (159mm) SOCKET HEAD W/NP 六角承窩螺絲 3/8" x 6 1/4"L 點耐落

14 1 5427301 P04-3826 WLDMT, G FRONT CONNECTOR 連接管組

15 2 5221401-A P02-4251 PLATE, 50 X 155 X 4MM 固定片

16 1 5427501 P04-3825 WLDMT, G REAR CONNECTOR 連接管組

17 1 5427901 P03-2724 GUIDE ROD, G LOWER 軸承鋼

18 1 5428001 P03-2723 GUIDE ROD, G UPPER 軸承鋼

19 1 54281PA P20-4303 PTD ASSY, G FOOT CARRIAGE 腳踏管組

20 14 2006503 BOLT, 1/4-20 X 3/4" (19mm) SOCKET HEAD W/NP 六角承窩螺絲 1/4" x 3/4"L 點耐落

21 3 5249001 P06-0134 CAP, HOLE 扣塞

22 2 5435901 P06-2989 BUSHING, GUIDE ROD 51 OD X 25.6 ID X 25 塑膠套管

23 2 5331601-A P05-0248 COLLAR, 25 ID SPLIT SHAFT 固定軸套

24 1 5212601 P06-2151 COVER, TOWER BASE 塑膠底座

25 32 2004802 SCREW, 10-32 X 1/2" (12MM) PAN HEAD W/NP 大扁頭十字螺絲 #10-32 X 1/2"L 點耐落

26 2 5209701 P01-3735 GUIDE ROD, 19 DIA X 1315 升降桿

27 15 52101PA P10-0778 PTD ASSY, 15 LB WEIGHT PLATE 15磅選擇片

28 1 5250201-C P20-2989 ASSY, 15 PLATE HEAD PLATE 上片組

29 1 5218201-D P20-2988 ASSY, 7.5LB INC. WEIGHT 配重塊組

30 2 5095301 A05-0212 SHAFT COLLAR, GUIDE ROD 固定軸套組

31 2 5209801 P06-2144 BUSHING, GUIDE ROD RETAINER 升降桿護套

32 2 5098201 P06-0034 CUSHION, WEIGHT STACK 橡膠墊

33 1 5429401 P17-0022 BELT, G TOWER 皮帶

34 1 5297701 LABEL, WEIGHT STACK 15LBS 磅數表

35 1 5429501 P04-3828 WLDMT, BELT TO CABLE CONNECTOR 滑輪固定片組

36 2 5208201-A P02-4266 PLATE, BELT CLAMP 固定片

37 2 2005404 BOLT, 3/8-16 X 1-1/4" (32mm) SOCKET HEAD 六角承窩螺絲 3/8" x 1 1/4"L

38 1 5428901 P13-0465 CABLE ASSY, G 連接鋼索

39 4 5094501 P06-0961 PULLEY, 4-1/2 OD X 25 大滑輪

Page 2

PARTS LIST
