Aerofit PLLE [7/12] Plle parts
![Aerofit PLLE [7/12] Plle parts](/views2/1135066/page7/bg7.png)
D20. End closure (8130-253)
(Pre-installed)
......................................... [2PCS]
D21. End closure (8130-249)
(Pre-installed)
......................................... [2PCS]
D22. Shaft (8220-184)
(Pre-installed)
.................................................... [2PCS]
D23. Flat head pop pin (8250-122G)
(Pre-installed)
.............................. [2PCS]
D24. Flat head pop pin (8250-125)
(Pre-installed)
................................. [1PCS]
D25. Copper sheath (8520-003)
(Pre-installed)
..................................... [4PCS]
D27. Chrome collar (8890-069)
(Pre-installed)
...................................... [2PCS]
D28. Skid handle (8890-070)
(Pre-installed)
.......................................... [1PCS]
D29. Foam grip (9162-002)
(Pre-installed)
............................................. [2PCS]
D30. Foam grip (9162-103)
(Pre-installed)
............................................. [2PCS]
D31. End cover (9211-157) .................................................................. [2PCS]
D32.Pulley spacer (8530-009)
(Pre-installed)
...........................................[2PCS]
D33.Pixture (9260-023)
(Pre-installed)
.....................................................[2PCS]
D34.Pulley spacer (8110-079)................................................................[2PCS]
D20 D21 D22 D24
D29D28D27D25
D23
D30
PLLE PARTS
6
D31
D32
D33
D34
