![Aerofit PLHP [7/13] H a r d w a r e](/img/pdf.png)
Aerofit PLHP [7/13] H a r d w a r e
![Aerofit PLHP [7/13] H a r d w a r e](/views2/1135076/page7/bg7.png)
H A R D W A R E
( s h o w n i n a c t u a l s i z e )
PLHP
D1.Cap Sleeve (9212-026).........................................
D2.Rubber lnsert (9310-076)......................................
D3.Bushing (9212-069)...............................................
D4.40X80 End Cap (9211-113) pre-installed 2...........
D5.Rubber Dount (9310-016)......................................
D6.Ø50 End Cap (9211-020).......................................
D7.25X50 End Cap (9211-086)....................................
D8.Conpression Spring (8840-018)..............................
D9.Shaft (8210-185) pre-installed.................................
D10.Key 6x6x30 pre-installed.......................................
D11.Impregnated with handle (9162-155) pre-installed.
D12.Pinch Cock (OC-06)..............................................
D13.Chrone Collar (8890-061) pre-installed.................
D14.Oilite Bushing (8520-005) pre-insralled.................
D15.Oilite Bushing (8520-002) pre-insralled.................
D16.Oilite Bushing (8520-001) pre-insralled.................
D17.Pulley (9266-009) pre-installed.............................
D18.Magnet (9546-104) pre-installed...........................
D19.Rubber Stopper (9310-018) pre-installed..............
D20.Railing (9215-008) pre-installed............................
D21.75X50 End Cap (9211-084)..................................
D22.Copper sheath (8530-024) pre-installed...............
D23.Bearing (8510-012) pre-installed..........................
[57PCS]
[6PCS]
[2PCS]
[4PCS]
[8PCS]
[4PCS]
[1PCS]
[1PCS]
[1PCS]
[1PCS]
[2PCS]
[4PCS]
[2PCS]
[2PCS]
[2PCS]
[4PCS]
[8PCS]
[1PCS]
[2PCS]
[1PCS]
[2PCS]
[16PCS]
[16PCS]
D1
D2
D3
D4
D5
D6
D7
D8 D9
D10
D11
D12
D13
D14
D15
D16
D17
D18
D19
D20
D21
6
D22
D23
