Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Main frame 1 24 Small round plug 2

2 Side frame 1 25 Big Plug 25 2

3 Pivot arm 1 26 Big plastic washer 1

4 Circular plate w/axle 1 27 Rubber sleeve 1

5 Weight holder 1 28 Bummper/Pad 1

6 Seat support 1 29 Spring collar 1

7 Adjustable foot frame 1 30 Spring collar plastic grips 2

8 Pop pin 2 31 Roller tube 1

9 Long pop pin 1 32 Collar 1

10 Rear base 1 33 End cap for shaft 1

11 Bronze bushing 2 34 Grip 32x23x185 2

12 Plastic washer 1 35 Grease fitting 1

Foot Cap 1 □50.8

3 36 Pivot tension pin 1

Foot Cap 2 □50.8

3 37 Screw M8*6 1

15 Stopper prong 1 38

Button head socket cap screw M10*70

16 Plastic guide sleeve 4 39

Button head socket cap screw M10*80

17 Plastic tube for foam pad 1 40

Button head socket cap screw M10*25

18 Long uphoistered roller pad 1 41

Button head socket cap screw M8*25

19 Uphoistered roller pad 2 42

Washer10，11*23*2

20 Seat pad 1 43

Washer8，9*16*1.6

21 Plug 38 3 44 Nylon lock nut10 5

22 Plug 44.5 3 45 Hex Key S=4 1

23 Hex Key S=6 1 46 Wrench 1
