Aerofit CTH1100 [3/10] Cth 1100

ASSEMBLY INSTRUCTIONS

Page

inch

60 130120

110

10090

8070

140

150

CTH-1100

CTH110.1-082008

1.2

(C1)3/8" ROUDN END CAP WASHER QTY.4

(B1)NYLON LOCK NUT M8 QTY.2

(B2)NYLON LOCK NUT M10 QTY.6

(C2)M8 SPRING WASHER QTY.4

(C3)M8(I.D.)FLAT WASHER Ø18X1.5T QTY.4

(C4)M8(I.D.)FLAT WASHER Ø24X1.6T QTY.4

(C5)M10(I.D.)FLAT WASHER Ø19X1.5T QTY.4

HARDWARE ILLUSTRATION

(C7)1/2"(I.D.)FLAT WASHER Ø25X2T QTY.2

(C6)M10(I.D.)FLAT WASHER Ø27X1.6T QTY.4

(B4)NYLON LOCK NUT 1/2" QTY.2

(C8)1/2" SPRING WASHER QTY.2
