UUssiinngg mmeetthhoodd ooff ccoonnttrrooll sseeccttiioonn

((LLHH--55331111FFNN))

Press “Power” button.

“Mode” for Mode/sleeping function, “CO” for time control function and “ON” for warm

humidification function are displayed, and present humidity is displayed depending on ambient humidity.

Select desired mist volume with “Mist Volume” button.

 Whenever you press “Mist Volume” button once, the stage of Mist Volume is displayed in the order of “

3rd stage, 4th stage, 1st stage, 2nd stage”.

Mode/Sleeping function fixes the optimal mist volume in comsideration of temperature and humidity.

Select Warm Mist fumction with “Warm Mist” button.

When you press “Warm Mist” button once, humidification condition is displayed in the order of warm Mist

and cool Mist.

If you select warm Mist, after about 10-15 minutes, procuct will spray warm mist(Humidity

temperature:about 40°C-45°C)

Press Mode/Sleeping button.

Whenever you press Mode/Sleeping button, the function is displayed in the order of

AUTO(Automatic)  SLEEP(Sleeping)  NONE(Manual)

If you select AUTO(Automatic mode), the optimal humidification in consideration of ambient temperature and

humidity is maintained. (Mist volume and desired humidity is automatically controlled, Warm Mist function is show

as ON, and Timer mode is shown as “CO”)

If you select SLEEP(sleeping) mode, the optimal humidification for sleeping in consideration of amvient tempera-

ture and humidity is maintained. (Mist volume and desired humidity is automatically controlled, Warm Mist mode

is shown as ON, and timer mode is shown as “CO”)

If you select Maunual mode, desired humidity is fixed as 60%, time is fixed as “CO”, and Mist volume is fixed as

3rd stage. And desired humidity, time and Mist volume is fixed manually by each button.

“REFILL” Alarm Function

If “FEFILL” alarm melody rings once, use product again after having turned off main switch and having

filled water tank with water.

“Cleaning” Time Alarm Function

When you have used product for 1.5 months, cleaning time alarm lamp tells you cleaning time.

At the time, after having turned off main switch and having cleaned the inside, press main

switch button for 2 seconds.

Select desired humidity with “Humidity Set.” Button.

Whenever you press “Humidity Set.” button once,

Humidity is displayed in the order of 60  65  70  75  Co  40  45  50  55

 Mode/Sleeping function fixes the optimal desired humidity in consideration of temperature and humidity.

Select desired operating time with “Time” Button.

 Whenever you press “Time” button once, Time is displayed in the order of “1hour... 9hours” or “CO”.

CO” stands for Continuous operating which means it will work without stopping.

All functions are stopped after the fixed time(1~9hrs)have passed.

In case that present humidity becomes higher than desired humidity by 3%, spray is stopped automatically, in case that

present humidity becomes lower than desired humidity, spray begins again and appropriate humidity is maintained.
