1 To connect the hose, push it rmly into the appliance (‘click’). Make

sure the recess in the hose connection ts exactly on the projection

on housing of the appliance.

2 To disconnect the hose, push the buttons (1) and pull the hose out

of the appliance (2).



1 To connect the telescopic tube to the handgrip:

- Telescopic tube with conical connection (specic types only): Insert the

handgrip into the telescopic tube and turn a little.

- Telescopic tube with button connection (specic types only): Press the

spring-loaded lock button on the handgrip and insert the handgrip into

the telescopic tube. Fit the spring-loaded lock button into the opening

in the tube (‘click’).

, To disconnect the telescopic tube from the handgrip:

- Telescopic tube with conical connection (specic types only): Pull the

handgrip out of the telescopic tube while turning it a little.

- Telescopic tube with button connection (specic types only): Press the

spring-loaded lock button and pull the handgrip out of the tube.
