DDE DPG9551E [2/2] Dde dpg9551e арт dpg9551e

Technical department Assembly drawing

Engineer, chief designer John Emerson Jr.

DYNAMIC DRIVE EQUIPMENT, USA

Page 2

DDE DPG9551E (арт. DPG9551E)

NO. АРТИКУЛ QTY NO. АРТИКУЛ QTY

1 Болт М6х60 M6X60 1 89 B5789-06KG-190C M6X185 FLANGE BOLT M6X190 4

2 7201-9900-0042 Крышка клапанов 1 90 B5787-05KG-235B M5X235 FLANGE BOLT M5X235 2

3 7201-9900-0041 Прокладка rubber w asher 1 91 31401-A120-0013 WIRING TERMINAL BLOCK 1

4 14201-E88F-2000 WASTE GAS TUBE 1 92 31610-B140-0002 CARBON BRUSH 1

5 14434-E88F-0000 NUT,PIVOT ADJ M6 HEX NUT M6 hex nut 2 93 B809-0500-000B M5 BALL NUT M5 2

6 14432-E88F-000

0 NUT,PIVOT M6 M6 spherical nut 2 94 B93-050G-000B SPRING GASKET 2

7 14431-E88F-0000 ARM ,VALVE ROCKER 2 95 55005-G5A3-0000 ANTI-DUCT RUBBER 1

8 14433-E88F-0000 BOLT PIVOT M6XM8X53 2 96 B5787-08LG-040C M8X40 FLANGE BOLT 8

9 14445-E88F-0000 RETAINER, IN,VALVE SPRING 1 97 11200-E88F-0200 COVER,CRANKCASE 1

10 14447-E88F-0000 ROTATOR,EXH VALVE 1 98 B9877.1-3552-A000 САЛЬНИК (или арт.7201-9900-0018) 2

11 14446-E88F-0000 RETAINER,EXH VALVE SPRIN

G 1 99 55006-G5B8-0000 WIND LEAD COVER 1

12 14751-E88F-0000 VALVE SPRING 2 100 B5787-05JG-012C M5X12 FLANGE BOLT M5X12 1

13 14448-E88F-0000 RETAINER,IN,VALVE SPRING 1 101 15002-E68F-0000 RUBBER PLATE 1

14 14444-E88F-B000 SEAL, IN VALVE 1 102 7201-9900-0061 МАГНЕТО 1

15 14449-E88F-0000 LIMIT POSITION PANEL 1 102-1 33-215 КОЛПАЧЕК СВЕЧНОЙ 1

16 B5789-10LJ-080C BOLT FLANGE M10X80 M10X80 4 103 B5789-06KG-025C M6X25 FLANGE BOLT M 6X25 2

17 2101-2900-01

51 СВЕЧА F7RTC(OREGON 77-312-1) 1 104 15300-E88E-0000 FLYWHEEL COMP 1

18 12005-E68F-000C BOLT,STUD M8X48.5 M8X35 2 105 15004-E88F-0100 COOLING FAN 1

19 18010-E88F-0000 WASHER,MUFFLER 2 106 E001.009.00500001 ХРАПОВИК СТАРТЕРА 1

20 B895-085G-000B SPRING WASHER φ8.5 2 107 B6177.1-16MG-001C M16 FLANGE NUT M16X1.5 1

21 B6170-0800-000C HEX NUT M8 M8 2 108 15600-E88F-06RE СТАРТЕР (или арт.7201-9900-0000) 1

22 53100-G7A1-20B3 COMP,MUFFLER 1 109 B5789-0

6KG-012C M6X12 FLANGE BOLT M6X12 5

23 53217-G5AA-000C SUPPORTING LEG, MUFFLER 1 110 11015-E88F-0000 CLAMP 3

24 B5789-06KG-012C FLANGE BOLT M6X12 2 111 11015-E88F-0200 CLAMP 1

25 B5787-08LG-040C FLANGE BOLT M8X40 1 112 34000-E88E-1000 STARTING MOTOR ASSY 1

26 B97.4-080G-000C WASHER φ 8 1 113 B5789-08LG-032C M8X32 FLANGE BOLT M8X32 2

27 B6177.1-08KG-000C FLANGE NUT M8 1 114 15200-E88F-0000 AC20 CHARGING COIL AC20 1

28 B5789-06KG-012C FLANGE BOLT

M6X12 M6X12 1 115 B5789-06KG-031C M6X30 FLANGE BOLT M6X30 2

29 11016-E88F-0000 WIND LEAD COVER 1 116 34101-E88F-0000 STARTING RELAY 1

30 12200-E90F-0000 CYCL HEAD 39.5CC, 1 117 34102-E88E-0000 CONNECTING CORD 1

31 12004-E88F-001C BOLT, STUD M6XM8X110 M6XM8X110 2 118 15001-E88E-0000 CAP,RELAY 1

32 17005-E88F-1000 GASKET,IN VALVE 1 119 15001-E88E-0000 CORD FIX PLATE 1

33 17001-E88F-0100 INSULATOR, CARB COMP 1 120 B5789-06KG-012C FLANGE BOLT M6X

12 2

34 17003-E88F-0100 PKG, CARB 1 121 51202-G5AA-00B4 BATTERY PLATE 1

35 17200-E90F-1008 CARBURETOR ASSY 1 122 029960200100 BATTERY (или арт.7201-9900-0138) 1

36 17004-E88F-1000 GASKET,A/C 1 123 B5789-08LG-095B FLANGE BOLT M8X95 2

37 B6177.1-08KG-000C FLANGE NUT M8 2 124 51304-G5AA-0000 SUPPORTING CUSHION 2

38 14200-E88F-0002 A/C ASSY 1 125 51330-G5B8-00B4 SUPPORTING ASSY. 2

39 12010-E90F-0000 GASKET,CYLN HEAD 1 126 B6177.1-08KG-000C FLANGE B

OLT M8 2

40 11014-E88F-0000 DOWEL,PIN 12X20 2 127 44008-0800-000B FLANGE NUT M8 2

41 14443-E88F-0000 EXH VALV E 1 128 7201-9900-0135 M6 ВИБРОГАСИТЕЛЬ 2

42 14442-E88F-1000 IN VALVE 1 129 51320-G8AA-02B4 M8X55 HANDLE ASSY 1

43 14410-E88F-0000 ROD,PUSH 5X166 2 130 51306-G5AA-0000 M6X20 PLASTIC HANDLE SET 1

44 14441-E88F-0000 LIFTER VALVE Φ9x46 2 131 B861.2-060G-000B RUBBER PAD 1

45 13010-E90F-0000 RING SET,PISTON 1 132 51219-G6A1-0000 GROUND TERMINALΦ6x

Φ10.5x120mm 1

46 13112-E88F-0000 CLIP PISTON PIN Φ1xΦ22.5 2 133 B6177.1-06KG-000C FLANGE NUT M6 1

47 13101-E90F-0000 PISTON 1 134 B5789-06KG-012C 125V/30A FLANGE BOLT M6X12 1

48 13111-E88F-0000 PIN PISTON Φ20x62 1 135 55012-G5AA-0000 M10 NYLON PAD 2

49 13200-E90F-0000 TIE ROD ASSY 1 136 51229-G5AA-0000 M8 FASTEN PIN 2

50 B5789-12LG-016C DRAIN PLUG M12X16 2 137 51312-G5AA-1000 HANDGRIP PLASTIC PLUG 2

51 B848-120H-0000 ALUM WASHER Φ12xΦ20x2 2 138 B6177

.1-10LG-000C FLANGE NUT M10 4

52 11100-E90E-0000 CRANKCASE 1 139 7201-9900-0135 M6 ВИБРОГАСИТЕЛЬ 2

53 16001-E88F-1000 SHAFT, GOVERNOR ARM 1 140 B6177.1-08KG-000C FLANGE NUT M8 2

54 B95-080G-000B GASKET,GOVERNOR ARM Φ8xΦ17x1 2 141 16006-G7A2-0000 POSITION PIN CLAM P 2

55 B13871-0814-A000 SEAL,GOVERNOR ARM Φ8xΦ14x5 1 142 51301-G5AA-0000 WHEEL SHAFT 2

56 16006-E88F-0000 PIN Φ1x8 1 143 51311-G5AA-0000 M6 WHEEL HUB COVER 2

57 B5787-06KG-016C FLANGE BOL

T M6X16 M6X16 2 144 51310-G5AA-0000 WHEEL ASSY. 2

58 7201-9900-0028 ДАТЧИК МАСЛА 1 145 B95-016G-000B M6X12 GASKET 2

59 B6177.1-10LG-000C FLANGE NUT M 10 M10 1 146 51312-G5AA-0000 FRAME PLUG 2

60 11013-E88F-0000 CLAMP, PIN LOCK Φ6.5 1 147 B5789-06KG-020B FLANGE BOLT M6X20 4

61 15030-E68F-1000 РЕЛЕ МАСЛА 3 ПРОВОДА three line 1 148 B5287-G7A2-000B FUEL TANK PAD 2

62 B5789-06KG-012C FLANGE BOLT M6X12 M6X12 1 149 54100-G5AA-00RE Φ6×Φ105x120 FUEL TANK AS

SY 1

63 14100-E90F-0001 CAM SHAFT ASSY 1 149-1 12003119 ДАТЧИК ТОПЛИВА В БАК 1

64 7201-9900-0030 ПОДШИПНИК 6202 1 149-2 3251-3900-9005 ПОБКА ТОПЛ. БАКА 1

65 13401-E90F-0000 GOVERNOR SHAFT 1 149-3 3251-3900-9006 ФИЛЬТР В БАК 1

66 B5789-06KG-012C FLANGE BOLT 1 149-4 54103-G5AA-0000 Φ12*Φ25*13 FUEL TANK RUBBER SLEEVE 4

67 16002-E88F-0000 GOVERNER ROD 1 149-5 54104-G5AA-0000 Φ9.5*Φ12*12 FUEL TANK CUSHION 4

68 16003-E88F-0000 ADJ SPRING 1 150 B5287-

G7A2-000B GASKET, TANK 4

69 16020-E88F-0000 GOVERNOR ARM 1 151 B5789-06KG-025B FLANGE BOLT M6X25 4

70 16031-E68F-000C BOLT,GOVERNOR ARM 1 152 54106-G7A1-000K 2P-30A CLAMP 2

71 B6177.1-06KG-000C FLANGE NUT M6 1 153 12003018 КРАН ТОПЛИВНЫЙ 1

72 16004-E88F-0000 SPRING THROTTLE RETURN 1 154 17002-E68F-1000 ШЛАНГ ТОПЛИВНЫЙ 0.42m

73 16300-E88F-0000 CONTROL ASSY 1 155 51100-G6AA-07B4 FRAME ASSY 1

74 13300-E90F-A000 CRANK ASSY 1 156 52000-G6AA-15H9 CONTRO

L PANEL ASSY 1

75 11012-E88F-1000 GASKET,CARANKCASE HEAD 1

76 11014-E68F-0000 DOWEL,PIN 2

77 7201-9900-0031 ПОДШИПНИК 6207 1

78 7201-9900-0030 ПОДШИПНИК 6202 1

79 16010-E88F-0000 GOVERNOR ASSY 1

80 7201-9900-0080 ЩУП МАСЛЯНЫЙ 1

81 31000-B154-0117 MOTOR ASSY 1

81-1 31200-B154-0004 ROTOR ASSY 1

81-2 31100-B154-0042 STATOR ASSY 1

82 B97.4-105G-000C PLATE WASHER M10X275 1

83 B5789-10LG-275C FLANGE BOLT,ROTORM10X275 1

84 B5787-05JG-012C FLANGE BOLT M

5X12 3

85 31301-G5A1-00RE END COVER 1

86 B5787-05JG-016C FLANGE BOLT M5X16 5 5

87 31700-G6A2-0000 БЛОК АВР 1 1

88 31502-G5A3-0000 BEARING SUPPORT 4 1

DDE DPG9551E [2/2] Dde dpg9551e арт dpg9551e
