11EN

Mountintothedashboard

1 If the car does not have an on-board drive

or navigation computer, disconnect the

negative terminal of the car battery.

• If you disconnect the car battery in

a car that has an on-board drive or

navigation computer, the computer

may lose its memory.

• If the car battery is not disconnected,

to avoid short-circuit, ensure that the

bare wires do not touch each other.

2 Ensure that car dashboard opening is

within these measurements:

3 Remove the mounting sleeve with the

supplied disassembly tools.

4 Install the sleeve into the dashboard and

bend the tabs outward to x the sleeve.

Note

• If the unit is not xed by sleeve but by the supplied

screws, skip this step.

183 mm

53mm

5mm

5 Place the supplied rubber cushion over the

end of the mounting bolt.

6 Slide the unit into the dashboard until you

hear a click.

183 mm

53.5 mm
