● i-Pro Camera Setup

Refer to each i-Pro camera Operational Manual.

i-Pro-

Cam

#

IP Address Subnet Mask Port MPEG4 Multicast Multicast

Address

Multicast

Port

1 172.16.192.4 255.255.0.0 80 On On 239.192.0.20 20000 Server IPA Default

2 172.16.192.5 255.255.0.0 80 On On 239.192.0.20 20002 Server IPA Default

3 172.16.192.6 255.255.0.0 80 On On 239.192.0.20 20004 Server IPA Default

Refer to WJ-GXD400 Operational Manual.

Dec# IP Address Subnet Mask Port OSD Position Authentication

Camera Title Time Date Additional Info

1 172.16.192.20 255.255.0.0 80 Left Lower -2 RightUpper+1 Left Lower -1 Default

● Network Disk Recorder WJ-ND400 Setup

Refer to WJ-ND400 Operational Manual.

NDR# IP Address Subnet Mask Port Recoder

Ch-Camera link

Camera Setup Schedule Authentication

1 172.16.192.21 255.255.0.0 80 Necessary Necessary Always Recording Default

from SX650 can be seen on the GXD400 monitor. The i-Pro video switch node consists of i-Pro cameras,

WJ-GXD400, WJ-NT314 and WJ-ND400. The SX650 video switch node contains a WJ-SX650 cage with Input,

Output and Network board (WJ-PB65E01). There are some video links from WJ-SX650 monitor output to

WJ-NT314 coaxial Input. The system also has WV-CU950 controller for system or local operators, and a PC station

with WV-ASC970 Admin Console.

Thesampledatabase–01=hybrid.adm,#=hybrid.gdm-andsys.inifile–01A=sys.ini-forAdministrationConsoleare

provided on the CD-ROM.
