INSTRUCTIONS FOR THE USER

It is necessary that all the operations regarding the installation, adjustment and adaptation to the type

of gas available are carried out by quali ed personnel, in conformity with the regulations in force.

The speci c instructions are described in the booklet section intended for the installer.

USING THE BURNERS

The symbols silk-screen printed on the side of the knob indicate the correspondence between the knob and the

burner.

• START-UP WITHOUT VALVES

Turn the corresponding knob anticlockwise up to the maximum position (large  ame,  g. 1) and press start-up button

P ( g. 1).

• AUTOMATIC START-UP WITH VALVES

Turn the corresponding knob anticlockwise up to the maximum position (large  ame,  g. 1) and press the knob. Once

the burner has been started up, keep the knob pressed for about 6 seconds.

• USING THE BURNERS

In order to obtain the maximum yield without waste of gas, it is important that the diameter of the pot is suitable for

the burner potential (see the following table), so as to avoid that the  ame goes out of the pot bottom ( g. 2).

Use the maximum capacity to quickly make the liquids reach the boiling temperature, and the reduced capacity to

heat food or maintain boiling. All of the operating positions must be chosen between the maximum and the minimum

ones, never between the minimum position and the closing point.

Use the maximum capacity to quickly make the liquids reach the boiling temperature, and the reduced capacity to

heat food or maintain boiling. All of the operating positions must be chosen between the maximum and the minimum

ones, never between the minimum position and the closing point.

The gas supply can be interrupted by turning the knob clockwise up to the closing position.

If there is no power supply, it is possible to light the burners with matches, setting the knob to the start-up point (large

 ame,  g. 1).

• NOTICE

• When the equipment is not working, always check that the knobs are in the closing position (see  g.1).

• If the  ame should blow out accidentally, the safety valve will automatically stop the gas supply, after a few

seconds. To restore operation, set the knob to the lighting point (large  ame,  g. 1) and press.

• While cooking with fat or oil, pay the utmost attention as these substances can catch  re when overheated.

• Do not use sprays near the appliance in operation.

• Do not place unstable or deformed pots on the burner, so as to prevent them from overturning or over owing.

• Make sure that pot handles are placed properly.

• When the burner is started up, check that the  ameis regular and, before taking pots away, always lowerthe

 ame or put it out.

INSTRUCTIONS FOR THE USER

BURNERS POWER (W) Ø of pots

Auxiliary 1000 10 - 14 cm

Semi-rapid 1750 16 - 18 cm

Rapid 3000 20 - 22 cm

Triple crown 3800 24 - 26 cm
