Freggia HB320X [13/44] Instructions for the installer

GB

13

INSTRUCTIONS FOR THE INSTALLER

ImPORTANT NOTICE:

THE OPERATIONS INDICATED BELOW mUST BE FOLLOWED BY QUALIFIED PERSONNEL ExCLUSIvELY,

IN CONFORmITY WITH THE REGULATIONS IN FORCE.

THE mANUFACTURING FIRm REFUSES ALLRESPONSIBILITYFOR DAmAGES TO PEOPLE, ANImALS OR

THINGS, RESULTING FROm THE FAILURE TO COmPLY WITH SUCH PROvISIONS

INSTALLATION

• All rooms require an openable window, or equivalent and some rooms will require a permanent vent a well.

• For room volumes up to 5m

3

an air vent of 100cm

2

• For room volumes between 5m

is required.

• If the room is greater than 5m

3

and has a door that opens directly to the outside, then no air vent is required.

installed next to cabinets, provided the height of the cabinet doses not exceed that of the hob.

The equipment must not be installed near inammable materials, such as curtains, cloths, etc.

Make a hole in the top of the piece of furniture, with the dimensions (see g.1/A), at a distance of at least 50 mm from

the appliance border to the adjacent walls.

Any possible wall unit over the cook-top must be placed at a distance of at least 700 mm from the top.

• FASTENING THE TOP

Every cook-top is equipped with a special washer having.

the cook-top in the hole made in the piece of furniture, then block it with the screws of the fastening hooks C (g. 3).

The connection must not stress the gas ramp.

Once the installation is over, check the connection seal with a soapy solution.

INSTRUCTIONS FOR THE INSTALLER
