INSTRUCTIONS FOR THE INSTALLER

Any possible wall unit over the cook-top must be placed at a

distance of at least 760 mm from the top.

It is advisable to isolate the appliance from the piece of furniture below with a separator, leaving a depression space

of at least 10 mm ( g. 4).

If the hob is going to be installed on the top of an oven, precautions must be taken to guarantee an installation in

accordance with current accident prevention standards. Pay particular attention to the position of the electric cable

and gas pipe: they must not touch any hot parts of the oven.

Moreover, if the hob is going to be installed on the top of a built in oven without forced cooling ventilation, proper

air vents must be installed to guarantee an adequate ventilation, with the lower air entering with a cross section of at

least 200cm

, and the higher air exiting with a cross section of at least 60cm

• FASTENING THE TOP

Every cook-top is equipped with a special washer. A set of hooks is also supplied for mounting the cook-top.

Depending on the type of mounting surface, the suitable type of mounting hook is supplied (hook A or hook B).

For the installation proceed as follows:

• Remove the racks and burners from the top.

• Turn the appliance upside down and lay the washer S along the external border ( g. 5).

• Introduce and place the cook-top in the hole made in the piece of furniture, then block it with the V screws

of the fastening hooks G ( g.6 / 6A).

• INSTALLATION ROOM

This appliance is not provided with a device for exhausting the products of combustion.

Regarding room ventilation rules where appliance is installed make reference to the legislation, in conformity with

the local regulations.

• FOR THE U.K. ONLY

The room containing this hotplate should have an air supply in accordance with BS 5440: Part 2: 1989.

• All rooms require an openable window, or equivalent and some rooms will require a permanent vent a

well.

• For room volumes up to 5m

an air vent of 100cm

is required.

• For room volumes between 5m

and 10m

an air vent of 50cm

is required.

• If the room is greater than 5m

and has a door that opens directly to the outside, then no air vent is required.

If there are other fuel burning appliances in the same room BS 5440: Part 2:1989 should be consulted to determine

the air vent requirements.

• GAS CONNECTION

Make sure that the appliance is adjusted for the gas type available (see the label under the appliance). Follow the

instructions indicated in the chapter “gas transformations and adjustments” for the possible adaptation to di erent

gases.

The appliance must be connected to the gas system by means of sti metal pipes or  exible steel pipes having

continuous walls, in compliance with the regulations in force.

Some models are equipped with both cylindrical A and conical B connectors for gas supply ( g. 7). Please select the

type which is correct for the supply concerned.

The connection must not stress the gas ramp.

Once the installation is over, check the connection seal with a soapy solution.

MODEL L (mm) P (mm)

600 560 480

INSTRUCTIONS FOR THE INSTALLER
