Samsung LE22B350F2W [18/61] Using your tv as a computer pc display

English - 16

Screen Mode → 16:9 / Wide Zoom / Zoom / 4:3

When setting the picture size to Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS

(Wide Screen Service) image or nothing. Each individual European country requires different picture size so this function is

intended for users to select it.

16:9: Sets the picture to 16:9 wide mode.

Wide Zoom: Magnify the size of the picture more than 4:3.

Zoom: Magnify the size of the picture vertically on screen.

4:3: Sets the picture to 4:3 normal mode.

This function is available in Auto Wide mode.

This function is not available in PC, Component or HDMI mode.

Digital NR → Off / Low / Medium / High / Auto

If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static

and ghosting that may appear on the screen.

When the signal is weak, select one of the other options until the best picture is displayed.

HDMI Black Level → Normal / Low

You can directly select the black level on the screen to adjust the screen depth.

This function is active only when the external input connects to HDMI (RGB signals).

Film Mode → Off / Auto

The TV can be set to automatically sense and process lm signals from all sources and adjust the picture for optimum quality.

Film Mode is supported in TV, AV, COMPONENT (480i / 1080i) and HDMI (480i / 1080i).

Picture Reset → Reset Picture Mode / Cancel

Resets all picture settings to the default values.

Select a picture mode to be reset. The reset is performed for each picture mode.

Reset Picture Mode: Current picture values return to default settings.

Using Your TV as a Computer (PC) Display

Setting Up Your PC Software (Based on Windows XP)

The Windows display-settings for a typical computer are shown below. The actual screens on your PC will probably be different,

depending upon your particular version of Windows and your particular video card. However, even if your actual screens look

different, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung

Dealer.)

First, click on ‘Control Panel’ on the Windows start menu.

When the control panel window appears, click on ‘Appearance and Themes’ and a display dialog-box will appear.

When the control panel window appears, click on ‘Display’ and a display dialogbox will appear.

Navigate to the ‘Settings’ tab on the display dialog-box.

The correct size setting (resolution) - Optimum: 1360 X 768 pixels.

If a vertical-frequency option exists on your display settings dialog box, the correct value is ‘60’ or ‘60 Hz’. Otherwise, just click

‘OK’ and exit the dialog box.



●



❑

●
