Technical Specifications
9
6 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications
1
of the PT-102AN / PT-102SN
PT-102AN PT-102SN
INPUTS: 1 unbalanced stereo audio on a
3.5mm mini plug connector
1 s-Video on a 4-pin connector
OUTPUTS: 2 unbalanced stereo audio on 3.5mm
mini plug connectors
2 s-Video on 4-pin connectors
MAX. OUTPUT LEVEL: 5Vpp 1.3Vpp
BANDWIDTH (-3dB): >100kHz 150MHz
DIFF. GAIN: - 0.05%
DIFF. PHASE: - 0.05 Deg
K-FACTOR: - <0.05%
S/N RATIO: 85dB @1kHz 76dB @5MHz
CONTROLS: Level: -55dB to +20dB Gain: luma: -1.9dB to +5.1dB
chroma: 0dB to +6.8dB, @5MHz
COUPLING: AC AC
AUDIO THD + NOISE: 0.01% @1kHz -
AUDIO 2
nd
HARMONIC: 0.004% @1kHz -
POWER SOURCE: 12V DC, 20mA 12V DC, 25mA
DIMENSIONS: 6.22cm x 5.18cm x 2.44cm (2.45" x 2.04" x 0.96") W, D, H.
WEIGHT: 0.14kg (0.31lbs) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: 19” rack adapters
1 Specifications are subject to change without notice
